Charles McMurray Co. 2023 Catalog

1358i / 1645

Track
78-3/4" or 98-7/16"
single running,
screw-on, aluminum
78-3/4" or 98-7/16"
single running,
pre-drilled, ceiling
mounted, aluminum
78-3/4" or 98-7/16"
single running,
pre-drilled, wall
mounted, aluminum
1300 mm (51-3/16")
groove mounted bottom
guide, plastic
For further information
on Hawa Junior 100Z
visit:
10/24
Hawa Junior 100 Z
Sliding Door System for Wood Doors
with Soft-Close/Stop-Open
• Maximum door weight: 220 lbs.
• Maximum door width: 3000 mm (118-1/8")
• Maximum door height: 4000 mm (157-1/2")
• Door thickness: 35-80 mm (1-3/8" to 3-3/16")
• Hardware for (1) top-running sliding door
• SoftStop or SoftMove integrated Soft-Close/Soft-Open mechanism
• Door installation from the side or front with height adjustment
• Optional aluminum clip-on fascia and SoftMove soft-close (order separately)
See next pg. for specs
Order hardware set, track and accessories separately.
Set No. Description List Set
Hawa Junior 100Z Hardware Set w/SoftMove $893.66
Hawa Junior 100Z Hardware Set w/SoftStop $399.92
Upper track and bottom guide, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Bottom guide - 1300 mm (51-3/16") $28.68
2000 mm (78-3/4") $216.56
Ceiling mount - 2000 mm (78-3/4") $227.04
Wall mount - 2000 mm (78-3/4") $264.56
2500 mm (98-7/16") $271.16
Ceiling mount - 2500 mm (98-7/16") $283.80
Wall mount - 2500 mm (98-7/16") $330.72
Hardware Set SM SS
2-wheel, ball-
bearing running
gear
2
SoftStop Junior
80/100 end stop
w/adjustable
retention spring
2
2-way suspension
plate 2 2
Zero tolerance
bottom guide,
groove width
7/16", plastic
1 1
Vertical adjustment
pin 1 1
SoftMove 100
magnetic soft-
close w/running
gear, end stop and
cover, pre-mounted
2
Mounting hardware included
Soft-Close
SoftMove 100 magnetic
soft-close w/running
gear, end stop and
cover, pre-mounted
Sold per each. Order two per door for
soft-close/soft-open - (2) included in
HW-JR100Z-SM SoftMove set. Mounting
hardware included.
Item No. List Ea.
$379.46
Clip-on Fascia
2000 mm (78-3/4") or 2500
mm (98-7/16") panel clips to
running track, aluminum
Fascia end, left,
2-5/16", aluminum
Fascia end, right,
2-5/16", aluminum
Fascia clip, for wood or
aluminum panel, pre-drilled,
aluminum
Handed end caps, sold per each.
Includes mounting hardware.
Item No. Description List Ea.
End fascia (L) $92.38
End fascia (R) $92.38
Panels, sold per each.
Item No. Length List Ea.
HW-JR-27685 78-3/4" $176.80
98-7/16" $221.00
Clips attach every 500 mm (19-11/16").
Sold per set.
Item No. List Ea.
$21.18
