Charles McMurray Co. 2023 Catalog

1358h / 1645

Track
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
screw-on, aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
pre-drilled, ceiling
mounted, aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
pre-drilled, wall
mounted, aluminum
1300 mm (51-3/16")
groove mounted bottom
guide, plastic
Hardware Set
2 2-wheel runninggear, plastic wheels
2
End Stop w/
adjustable
retention spring
2 2-way suspensionflange, steel
1
Zero tolerance
bottom guide,
groove width 7/16",
plastic
1 Door stop,screw-on, rubber
1 Vertical adjustmentpin
Mounting hardware included
10/24
Hawa Junior 80 Z
Sliding Door System for Wood Doors
Order hardware set, track and accessories separately.
Set No. Description List Set
Hawa Junior 80Z Hardware Set $361.32
Upper track and bottom guide, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Bottom guide - 1300 mm (51-3/16") $28.68
2000 mm (78-3/4") $216.56
Ceiling mount - 2000 mm (78-3/4") $227.04
Wall mount - 2000 mm (78-3/4") $264.56
2500 mm (98-7/16") $271.16
Ceiling mount - 2500 mm (98-7/16") $283.80
Wall mount - 2500 mm (98-7/16") $330.72
• Maximum door weight: 176 lbs.
• Maximum door width: 3000 mm (118-1/8")
• Maximum door height: 4000 mm (157-1/2")
• Door thickness: 35-80 mm (1-3/8" to 3-3/16")
• Hardware for (1) top-running sliding door
• Door installation from the side or front with height adjustment
• Optional soft-close and aluminum clip-on fascia (order separately)
Soft-Close
SoftMove 80 soft-close
mechanism
See pg. 1358g for specs
Sold per each. Order two per door for
soft-close/soft-open. Mounting hardware
included.
Item No. List Ea.
$278.24
For further information
on Hawa Junior 80Z
visit:
Clip-on Fascia
2000 mm (78-3/4") or 2500
mm (98-7/16") panel clips to
running track, aluminum
Fascia end, left,
2-5/16", aluminum
Fascia end, right,
2-5/16", aluminum
Fascia clip, for wood or
aluminum panel, pre-drilled,
aluminum
Handed end caps, sold per each.
Includes mounting hardware.
Item No. Description List Ea.
HW-JR-30141 End fascia (L) $92.38
HW-JR-30142 End fascia (R) $92.38
Panels, sold per each.
Item No. Length List Ea.
HW-JR-27685 78-3/4" $176.80
HW-JR-30331 98-7/16" $221.00
Clips attach every 500 mm (19-11/16").
Sold per set.
Item No. List Ea.
HW-CLIP-FASCIA $21.18
