Charles McMurray Co. 2023 Catalog

1358g / 1645

Hardware Set
4 2-wheel, ball-bearingrunning gear
4 2-way suspensionflange, steel
2
Zero tolerance bottom
guide, groove width
7/16", plastic
1
Stopper with
adjustable retention
spring
2 Guide pulley wheel
1 Toothed belt lock (formanual systems)
1
Laterally adjustable
drive (for manual
systems)
1 384-3/4" toothed belt,fiberglass reinforced
2 Door stop, screw-on,rubber
1 Vertical adjustmentpin
Mounting hardware included
Toothed belt length calculated for (2) slid-
ing doors with max. width 47-1/4" each.
05/24
Hawa Junior 80 Z Symmetric
Sliding Door System for Wood Doors
Order hardware set, track and accessories separately.
Set No. Description List Set
Hawa Junior 80Z Symmetric Hardware Set $1,372.56
Upper track and bottom guide, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Bottom guide - 1300 mm (51-3/16") $28.68
2000 mm (78-3/4") $216.56
2500 mm (98-7/16") $271.16
• Maximum door weight: 176 lbs.
• Door width: 500 mm-1200 mm (19-11/16" to 47-1/4")
• Maximum door height: 4000 mm (157-1/2")
• Maximum door opening: 2400 mm (94-1/2")
• Door thickness: 35-80 mm (1-3/8" to 3-3/16")
• Hardware for (2) symmetrically opening top-running sliding doors
• Door installation from the side or front with height adjustment
NOTE: Soft-close hardware cannot be used with Hawa Junior 80 Z Symmetric
For further information on
Hawa Junior 80Z Symmetric
visit:
Installation examples Track
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
screw-on, aluminum
1300 mm (51-3/16")
groove mounted bottom
guide, plastic
