Charles McMurray Co. 2023 Catalog

1358o / 1645

• Maximum door weight: 220 lbs.
• Maximum door width: 1600 mm (63")
• Maximum door height: 2700 mm (106-5/16")
• Door thickness: 30-80 mm (1-3/16" to 3-3/16")
• Optional soft-close
Soft-Close SC22 SC133
Top-running
soft-close
(133-220
lbs.), plastic
1
Soft-close
trigger, zinc 1 1
Top-running
soft-close
(22-132
lbs.), plastic
1
Sold per each. Order two per door for
soft-close/soft-open. Mounting hardware
included.
Item No. List Ea.
HW-PORTA-SC22 $255.34
HW-PORTA-SC133 $255.34
Sold per each.
Item No. List Ea.
$14.54
Hardware Set
2 Ball-bearing runninggear w/plastic rollers
2 End Stop w/retentionspring, plastic
2 Suspension bolt (5/16"x 1-1/4"), steel
2 Hexagon locking nut,steel
2
Height/lateral
adjustable support
bracket, steel
1 Adjustable bottomguide w/roller, plastic
Mounting hardware included
Track
2000 mm (78-3/4") single
running, screw-on, pre-
drilled, aluminum
2500 mm (98-7/16") single
running, screw-on, pre-
drilled, aluminum
Accessories
Track cleaner, plastic
Order hardware set, track and accessories separately.
Hardware for (1) top running sliding door.
Set No. Description List Set
Hawa Porta 100H Hardware Set $204.96
Track, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Ceiling mount - 2000 mm (78-3/4") $130.96
Ceiling mount - 2500 mm (98-7/16") $179.44
Assembly set: includes demountable track and assembly pin, sold per set. (Track can
be removed after installation.) Mounting hardware included.
Item No. Description List Set
Assembly set - 2000 mm (78-3/4") $204.60
Assembly set - 2500 mm (98-7/16") $254.38
Track Assembly Set 78" 98"
2000 mm
(78-3/4")
single running,
pre-drilled,
aluminum
1
2500 mm
(98-7/16")
single running,
pre-drilled,
aluminum
1
Assembly pin,
plastic 9 11
(Track is demountable and can be removed
after installation.)
10/24
Hawa Porta 100 H
Sliding Door System for Wood Doors
See pg. 1358q for specs
