Charles McMurray Co. 2023 Catalog

1358p / 1645

• Maximum door weight: 220 lbs.
• Maximum door width: 1200 mm (47-1/4")
• Maximum door height: 2700 mm (106-5/16")
• Door thickness: 30-80 mm (1-3/16" to 3-3/16")
Synchro Set
2 Ball-bearing deviatingroller
2 Cable safety, steel
2 Clamp, steel
1 Cable (3/32"), Kevlar ®
2 Flat washer (3/16",19/32", 3/32"), steel
Mounting hardware included
Hardware Set
2 Ball-bearing runninggear w/plastic rollers
2 End Stop w/retentionspring, plastic
2 Suspension bolt (5/16"x 1-1/4"), steel
2 Hexagon locking nut,steel
2
Height/lateral
adjustable support
bracket, steel
1 Adjustable bottomguide w/roller, plastic
Mounting hardware included
Order hardware set, track, and synchro set separately.
Hardware for (1) top-running sliding door, order (1) set per door.
Set No. Description List Set
Hawa Porta 100H Hardware Set $204.96
Track, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Ceiling mount - 2000 mm (78-3/4") $130.96
Ceiling mount - 2500 mm (98-7/16") $179.44
Assembly set: includes demountable track and assembly pin, sold per set. (Track can
be removed after installation.) Mounting hardware included.
Item No. Description List Ea.
Assembly set - 2000 mm (78-3/4") $204.60
Assembly set - 2500 mm (98-7/16") $254.38
Maximum door width: 47-1/4" per
door for (2) synchronously opening, top-
running doors. Sold per set. Order (1)
set per two doors, mounting hardware
included.
Item No. List Ea.
$320.08
Track Assembly Set 78" 98"
2000 mm
(78-3/4")
single running,
pre-drilled,
aluminum
1
2500 mm
(98-7/16")
single running,
pre-drilled,
aluminum
1
Assembly pin,
plastic 9 11
(Track is demountable and can be removed
after installation.)
Sold per each.
Item No. List Ea.
$14.54
Accessories
Track cleaner, plastic
Track
2000 mm (78-3/4") single
running, screw-on, pre-
drilled, aluminum
2500 mm (98-7/16") single
running, screw-on, pre-
drilled, aluminum
10/24
Hawa Porta 100 H Synchro
Sliding Door System for Wood Doors
See next pg. for specs
For further information on
Hawa Porta 100H Synchro
visit:
NOTE: Soft-close hardware cannot be
used with Porta 100 H Synchro.
