Charles McMurray Co. 2023 Catalog

Accessories

1221 Door Guide

: For use with 1222 guide channel.

Attaches to bottom of lead door and runs in guide

channel. 3/4"x3-1/2"x3/32". Zinc-plated steel plate

and post. Guide roller is oilite bronze.

Item No. Box List Ea.

List Ea.

Full Box

GR1221

20 $27.64

$23.48

1222 Continuous Guide Channel

: For use

with 1211 or 1221 guide roller. Mortised into floor

or surface mounted. 5/8"H x 3/4"D. Aluminum

.093" thick.

Item No. Length Box List Ea.

List Ea.

Full Box

GR1222-8

5 $80.46 $67.54

GR1222-12

12'

5 $113.52 $96.20

Framing and Panel Sizes:

Finished opening to be a minimum of panel height plus 4-1/4".

(Allows no adjustment.)

Maximum vertical adjustment top of door to header is 1/2".

Maximum vertical adjustment bottom of door to floor is 1".

Maximum adjustment header to floor is 1-1/2".

Hardware Set Includes

1 1205 carrier with pendant bolt &

top plate

1 1234 bottom pivot plate as-

sembly

1 1223 floor pivot bolt assembly

1 1269 top pivot post assembly

1 1224 bottom pivot pin plate

1 1255 top pivot clamp assembly

screws & instructions

1223 floor pivot bolt

assembly

1255 top pivot

clamp assembly

1269 top pivot post

assembly

1224 bottom pivot pin plate

1234 bottom pivot plate assembly

1201 track, sold separately

1205 carrier w/pendant

and top plate

Components

GR1260

Heavy-Duty Bi-Fold Door Hardware

For Doors 1" Minimum, Up To 175 lbs. Each

For 1" or thicker doors.

Adjustment: 0" to 1-1/2" vertical.

Headroom: 3-1/4 to 3-3/4".

Using door guide channel 1222

and door guide 1221 mortised

into floor or surface mounted.

Bulk Pack - Track & hardware sold separately

Track

Item No.

Length Box List Ea.

List Ea.

Full Box

GR1201-8

5 ea $122.52 $103.84

GR1201-12

12'

5 ea $166.92 $142.70

Hardware Set

Set No.

Box

List Set

Full Box

GR1260

5 sets

$227.28

$192.62

• For door panels 1" minimum and up

• 4-wheel carrier with precision ball-bearing wheels for

quiet, effortless operation

• Aluminum I-beam track, pre-drilled for easy installation

• Meets and/or exceeds ANSI/BHMA standards

Floor guide channel and door guide optional, order separately.

DOOR

HARDWARE

TOOLS FASTENERS SHOP &

FINISHING

ABRASIVES LACQUERS &

FINISHES

ADHESIVES FURNITURE

HARDWARE

EDGING &

DECOR.WOOD

SHELF &

CLOSET

ORGANIZERS

KITCH./BATH

LIGHTING SLIDES

DOORS &

DRAWERS

LOCKS &

CATCHES

AVENTOS &

LIFTS

CABINET

HINGES

DECORATIVE

HARDWARE

DOOR LOCKS & HARDWARE

800.533.0533

1356

Prices subject to change without notice.
