Charles McMurray Co. 2023 Catalog

1358a / 1645

Hardware Set
2-wheel running gear,
plastic wheels
End Stop w/ adjustable
retention spring*
Zero tolerance bottom
guide, 7/16"W groove,
plastic
Screw-on door stop,
rubber
Suspension profile and
plate
Suspension profile w/bolt,
plate and locking wrench
Mounting hardware included
*Set includes (1) end stop, order 27771
separately if second end stop is required
for application (available by special order.)
05/24
Hawa Junior 80 B - Mortised
Pocket/Sliding Door System for Wood Doors
Minimal Installation Height - Surface Mount
(Minimum 1mm gap between door and track)
For standard or pocket door: Order hardware set, track and accessories separately.
Set No. Description List Set
Hawa Junior 80B Hardware Set $582.30
Upper track and lower guide, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Bottom guide - 1300 mm (51-3/16") $28.68
HW-JR-TRACK-78* 2000 mm (78-3/4") $216.56
HW-JR-TRACK-78CM Ceiling mount - 2000 mm (78-3/4") $227.04
HW-JR-TRACK-78WM Wall mount - 2000 mm (78-3/4") $264.56
HW-JR-TRACK-98* 2500 mm (98-7/16") $271.16
Ceiling integrated - 2500 mm (98-7/16") $366.52
HW-JR-TRACK-98CM Ceiling mount - 2500 mm (98-7/16") $283.80
HW-JR-TRACK-98WM Wall mount - 2500 mm (98-7/16") $330.72
*For use in pocket door application
• Maximum door weight: 176 lbs.
• Maximum door width
Pocket door application: 1500 mm (59-1/16")
Standard application: 3000 mm (118-1/8")
• Maximum door height: 4000 mm (157-1/2")
• Door thickness: 35-80 mm (1-3/8" to 3-3/16")
• Hardware for (1) top-running sliding door (suspension plate is mortised into door)
• Door installation from the side or front with height adjustment
• Optional soft-close, aluminum clip-on fascia and accessories (order separately)
Soft-Close
SoftMove 80 soft-close
mechanism
Sold per each. Order two per door for
soft-close/soft-open. Mounting hardware
included.
Item No. List Ea.
HW-JR80-SOFTMOVE $278.24
Pocket/Sliding
Demountable Track Profile
2035 mm (80-1/8")
or 2535 mm (99-13/16")
retainer profile with
bayonet lock, aluminum
For pocket door application. Sold per each,
order one per door. Mounting hardware
included. (Order track separately.)
Item No.
Track
Length List Ea.
78-3/4" $307.72
98-7/16" $362.98
Handed end caps, soldper each.Includes
(1) left or right end fascia with mounting
hardware.
Item No. Description List Ea.
HW-JR-30145 End fascia (L) $80.44
HW-JR-30146 End fascia (R) $80.44
For further information
on Hawa Junior 80B
visit:
Track
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running, screw-on,
aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
pre-drilled, ceiling
mounted, aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running, pre-
drilled, wall mounted,
aluminum
2500 mm (98-7/16")
single running,
pre-drilled, ceiling
integrated, aluminum
1300 mm (51-3/16")
groove mounted bottom
guide, plastic
Clip-on Fascia
2000 mm (78-3/4") panel
clips to running track,
aluminum
Fascia end, left, 2-1/8",
aluminum
Fascia end, right, 2-1/8",
aluminum
Panels, sold per each.
Item No. List Ea.
HW-JR-27689 $88.94
