LEGRABOX - C Height (7") ORION GRAY or STAINLESS STEEL
Weight Capacities of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Interior Rollout Drawers Standard Drawers
Drawer Height: 177mm (7").
Minimum Opening Height: 193mm (7-5/8") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Drawer Height: 177mm (7").
Minimum Opening Height: 191mm (7-1/2") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(SOS-GR)
Stainless
(SOI-SS)
125 lb. Capacity
B770C27* 11" 10-5/8" $204.96 $293.90
B770C35* 14" 13-3/4" $204.48 $293.42
B770C40* 16" 15-3/4" $196.06 $287.44
B770C45* 18" 17-11/16" $197.76 $171.82
B770C50* 20" 19-11/16" $197.62 $293.88
B770C55* 22" 21-5/8" $208.34 $308.88
170 lb. Capacity
B773C4 18" 17-11/16" $214.46 NS
B773C5 20" 19-11/16" $214.32 $310.56
B773C5 22" 21-5/8" $225.02 $325.58
B773C6 24" 23-5/8" $255.64 $367.76
*Specify Gray (SOS-GR) or Stainless Steel (SOI-SS)
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets*
(All installation screws are included.)
*When building Interior Rollout Drawers, use
Front Fixing Brackets included in LB-C-INT kit.
For a complete list of components see catalog pgs 452-454.
For Interior Rollout Drawers
Use Standard Drawer Set + Interior Rollout Kit
LB-C-INT (Specify color when ordering)
Kit No.
List Per Kit
Gray (SOS-GR) Stainless (SOI-SS)
LB-C-INT* $146.54 $327.20
*Specify Gray (SOS-GR) or Stainless Steel (SOI-SS)
BZI7.3C Interior
Front Fixing Bracket Set
Front Piece
BZR7.1080U Cross Gallery Rail
(Required for interior rollout.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
(All installation screws are included.)
For TIP-ON
BLUMOTION
Units
(Touch-to-Open/
Soft-Close)
see page 451.
BZR7.1080U Cross Gallery Rail
1080 (42-1/2") (cut to size)
L=opening width minus 90 (3-1/2")
Rear
Fixing Bracket Set B770C Drawer Profile Set
B750/753 Cabinet Profile Set
Item No. Description
Gray
(OGM)
Stainless
(INGL)
Interior Drawer Parts
BZI7.3C* Interior front fixing bracket $65.62 st $106.06 st
BZV7.1043C01* Front piece $55.42 ea $131.94 ea
BZR7.1080U Cross Gallery Rail $25.50 ea $89.20 ea
Fixing Brackets Price pr.
Rear fixing bracket $6.16
EXPANDO front fixing bracket $2.44
*Specify Gray (OGM) or Stainless Steel (INGL)
Standard Drawer Components Interior Rollout Components
Front
Fixing Bracket
BZI7.3C Interior Front Fixing
Bracket Set
1043 mm (41-1/16") (cut to size)
L=inside cabinet width minus 126 (5")
H: 96 mm
Front Piece
DECORATIVE
HARDWARE
