LEGRABOX - M Height (3-9/16") ORION GRAY or STAINLESS STEEL
Weight Capacities of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets*
(All installation screws are included.)
*When building Interior Rollout Drawers, use
Front Fixing Brackets included in LB-M-INT kit.
For Interior Rollout Drawers
Use Standard Drawer Set + Interior Rollout Kit
LB-M-INT (Specify color when ordering)
Kit No.
List Per Kit
Gray (SOS-GR) Stainless (SOI-SS)
LB-M-INT* $105.28 $201.22
*Specify Gray (SOS-GR) or Stainless Steel (SOI-SS)
Interior Rollout Drawers Standard Drawers
Drawer Height: 90.5 mm (3-9/16").
Minimum Opening Height: 106 mm (4-3/16") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Drawer Height: 90.5 mm (3-9/16").
Minimum Opening Height: 104 mm (4-1/16") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
Stainless
(SOI-SS)
125 lb. Capacity
11" 10-5/8" $162.24 $211.46
14" 13-3/4" $161.76 $210.98
B770M40* 16" 15-3/4" $155.58 $206.58
B770M45* 18" 17-11/16" $156.86 $209.66
B770M50* 20" 19-11/16" $157.26 $211.84
B770M55* 22" 21-5/8" $167.36 $223.28
170 lb. Capacity
B773M45* 18" 17-11/16" $173.54 $226.34
B773M5 20" 19-11/16" $173.94 $228.52
B773M5 22" 21-5/8" $184.06 $239.96
B773M6 24" 23-5/8" $213.26 $275.58
*Specify Gray (SOS-GR) or Stainless Steel (SOI-SS)
For a complete list of components see catalog pages 452-454.
BZI7.0M Interior
Front Fixing Bracket Set
Front Piece (Required
for interior rollout.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
(All installation screws are included.)
08/22
BZI7.0M Interior Front Fixing
Bracket Set
Rear
Fixing Bracket Set
Front
Fixing Bracket B770M Drawer Profile Set
B750/753 Cabinet Profile Set
Item No. Description
Gray
(OGM)
Stainless
(INGL)
Accessories for Interior Drawer
BZI7.0M* Interior front fixing bracket $49.86 st $69.28 st
BZV7.1043C01* Front piece $55.42 ea $131.94 ea
Fixing Brackets Price pr.
Rear fixing bracket $4.70
EXPANDO front fixing bracket $1.34
*Specify Gray (OGM) or Stainless Steel (INGL)
Front Piece
1043 mm (41-1/16") (cut to size)
L=inside cabinet width minus 126 (5")
H: 96 mm (sits flush with top of M height drawer)
For TIP-ON
BLUMOTION
Units
(Touch-to-Open/
Soft-Close)
see page 451.
Standard Drawer Components Interior Rollout Components
