Charles McMurray Co. 2021 Catalog

451 / 1590

08/22
1 TIP-ON Unit
TIP-ON BLUMOTION for LEGRABOX
Front Gap Template
For creating a 2.5 (3/32") front gap
Item No. List Ea.
$19.28
Order LEGRABOX drawer sets separately.
See pages 446-450.
• Length 1118 (44-1/32") cut-to-size
• Inside cabinet width:
Minimum = 294 (11-9/16")
Maximum = 1365 (53-3/4")
• Recommended for all cabinet widths for optimal function
Item No. List Ea.
$14.56
• To be used with the BT60L1118W synchronization rod
• Two needed per application
Item No. List Ea.
$0.94
2 Synchronization Adapter (2 included with TIP-ON kit)
3 Synchronization Rods
For narrow applications:
• Length 64 (2-1/2") cut-to-size
• Inside cabinet width: Minimum = 261 (10-9/32")
Maximum = 285 (11-7/32")
Item No. List Ea.
$3.18
Rod length = opening width
minus 267 (10-1/2")
Rod length = opening width
minus 241 (9-1/2")
Do not use bumpers, as this
can inhibit the function of
TIP-ON BLUMOTION when
the drawer front is pressed.
3
3
• Enables LEGRABOX drawers to be opened
with just a light touch of the drawer front
• Fully mechanical motion
• Smooth running action
Includes left and right TIP-ON units &
triggers and2 synchronizationadapters.
Item No.
For
Length List Set
For up to 44 lbs.
11" only $49.88
14-22" $49.88
For 44-88 lbs.
14-22" $49.88
For 88-155 lbs.
18-24" $49.88
