Charles McMurray Co. 2021 Catalog

447 / 1590

08/22
LEGRABOX - N Height (2-5/8") ORION GRAY or STAINLESS STEEL
Weight Capacities of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Drawer Height: 66.5mm (2-5/8").
Minimum Opening Height: 80mm based on 3mm (1/8") clearance.
Minimum depth = actual profile length +3mm (1/8").
Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
Stainless
(SOI-SS)
125 lb. Capacity
B770N45* 18" 17-11/16" $159.74 $212.52
B770N50* 20" 19-11/16" $159.20 $213.78
B770N55* 22" 21-5/8" $169.98 $224.56
*Specify Gray (SOS-GR) or Stainless Steel (SOI-SS)
Standard Drawers
Optional TIP-ON Units for Touch-to-Open/Soft-Close
Includes left and right TIP-ON units &
triggers and2 synchronizationadapters.
Item No.
For
Length List Set
For up to 44 lbs.
11" only $49.88
14-22" $49.88
For 44-88 lbs.
14-22" $49.88
For 88-155 lbs.
18-24" $49.88
For more information and accessories see page 451.
NOTE: Interior rollout not available in N height.
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets
(All installation screws are included.)
For a complete list of components see catalog pages 452-454.
Rear
Fixing Bracket Set
N Front
Fixing Bracket
Components
B770N Drawer Profile Set B750/753 Cabinet Profile Set
Item No. Description Price pr.
Fixing Brackets
Rear fixing bracket $4.70
EXPANDO front fixing bracket $2.96
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 2021 1946 447 Prices subject to change without notice.
