415 / 1590
Runner setback when using all other locking devices
563
runner setback
563
runner setback
sub-front
thickness
13
(1/2")
17.5
(11/16")
20.5
(13/16")
23.5
(15/16")
sub-front
thickness
13
(1/2")
14.5
(9/16")
17.5
(11/16")
20.5
(13/16")
16
(5/8")
20.5
(13/16")
23.5
(15/16")
26.5
(1-1/32")
16
(5/8")
17.5
(11/16")
20.5
(13/16")
23.5
(15/16")
19
(3/4")
23.5
(15/16")
26.5
(1-1/32")
29.5
(1-5/32")
19
(3/4")
20.5
(13/16")
23.5
(15/16")
26.5
(1-1/32")
16
(5/8")
19
(3/4")
22
(7/8")
16
(5/8")
19
(3/4")
22
(7/8")
drawer front thickness
drawer front thickness
█
Setbacks in this table set the face of the drawer front flush with the face of the cabinet
█
If a depth adjustable locking device is needed, please see the locking device and table above
Calculating runner setback
563 (sub-front thickness + drawer front thickness minus
11.5
(7/16") = runner setback)
563 (sub-front thickness + drawer front thickness minus
14.5
(9/16") = runner setback
)
NOTE:
For mounting hole position, add
7
(9/32") to runner setback
mounting hole position
runner setback
NOTE:
runner cannot be
mounted below opening
drawer front
drawer sub front
Installation
Inset Drawer Application for B563 Drawer Slides
Runner setback when using depth adjustable locking device
(T51.1901.PS)
563
runner setback
563
runner setback
sub-front
thickness
13
(1/2")
20
(25/32")
23
(29/32")
26
(1-1/32")
sub-front
thickness
13
(1/2")
17
(21/32")
20
(25/32")
23
(29/32")
16
(5/8")
23
(29/32")
26
(1-1/32")
29
(1-5/32")
16
(5/8")
20
(25/32")
23
(29/32")
26
(1-1/32")
19
(3/4")
26
(1-1/32")
29
(1-5/32")
32
(1-1/4")
19
(3/4")
23
(29/32")
26
(1-1/32")
29
(1-5/32")
16
(5/8")
19
(3/4")
22
(7/8")
16
(5/8")
19
(3/4")
22
(7/8")
drawer front thickness
drawer front thickness
█
Setbacks in this table recess the face of the drawer front inside of the cabinet
1
(1/32
")
█
The depth adjustment can then be used to move the drawer front out to its desired position,
2.5
(3/32") out adjustment only
Calculating runner setback
563 (sub-front thickness + drawer front thickness minus
9
(11/32") = runner setback)
563 F/A (sub-front thickness + drawer front thickness minus
12
(15/32") = runner setback
)
NOTE:
For mounting hole position, add
7
(9/32") to runner setback
Setback information
NOTE:
For mounting hole position add 7 (9/32") to runner setback
