Charles McMurray Co. 2021 Catalog

410 / 1590

TANDEM plus BLUMOTION 563F Drawer Slides
Maximum Material = 3/4"
Full Extension, 100 lb. Capacity
Basic Components
locking devices
runner profile
optional
rear brackets
(face frame only)
NOTES: For inset applications see pages 414-415.
Item No.
Drawer
Length
Profile
Length
Panel Face Frame w/Rear Bkts
List Pr.
Minimum
Interior
Depth
Minimum
Interior Depth
Maximum
Interior Depth
229 (9") 259 (10-3/16")
Setback +
Profile Length
+3 mm
266 (10-15/32") 299 (11-25/32") $63.56
305 (12") 319 (12-9/16") 328 (12-29/32") 370 (14-9/16") $50.28
381 (15") 395 (15-9/16") 404 (15-29/32") 446 (17-9/16") $50.28
457 (18") 471 (18-17/32") 480 (18-29/32") 522 (20-9/16") $49.00
533 (21") 548 (21-9/16") 557 (21-15/16") 599 (23-19/32") $50.40
6 pair per box.
Accessories
Locking Devices - 100 pair per box, sold per pair.
Item No. Description List Pair
Standard $3.84
W/Side-to-Side Adjustment $6.76
For additional locking devices see page 420.
Rear brackets for face frame application see page 421.
Screws for slides& lockingdevices. Large flathead#6 x 5/8".
Item No. Box List c
1c $5.94
10c $32.00
Maximum drawer thickness is 19 mm (3/4").
Order slides, locking devices
and screws separately.
For complete specifications order Blum
Tandem catalog: B-TANDEM563/569
