TANDEM plus BLUMOTION concealed drawer runners offers four-
dimensional adjustment, elongated holes for depth adjustment,
bottom mount holes and exceptional load capacity.
TANDEM series runners are based on the American standard 3" cabinet
system; therefore, the runner lengths come in 3" increments.
TANDEM plus BLUMOTION runners are available for drawers from 9" - 30"
in length.
All Blum runners meet or exceed ANSI/BHMA 156.9 Grade 1 requirements.
Visit for additional help with TANDEM plus BLUMOTION
563 series.
Complete runner system
█ Full extension concealed runners with BLUMOTION soft close
█ Zinc-coated steel
█ Concealed roller carriage with permanently lubricated synthetic rollers
█ Available in standard and heavy duty
█ H and . series for drawers up to 5/8" side material thickness
█ F series for drawers up to 3/4" side material thickness
█ Elongated holes for depth adjustment
█ Bottom mount holes on 15", 18" and 21" standard duty
█ Tool-free tilt adjustment
█ Tool-free rear side-to-side adjustment
Locking devices
█ Stamped steel or zinc die-cast base with synthetic, spring-loaded release levers
█ Captive right device, self-aligning left device
█ Self-adjusting drawer length tolerance
█ Tool-free height adjustment
█ Tool-free front side-to-side adjustment
█ Available with depth adjustment
█ Available for narrow drawers
Rear mounting options
█ Zinc-coated steel brackets or nylon sockets
█ Depth and lateral self-alignment
One runner for all applications
TANDEM runners are designed for the American 3" increment cabinet depth
system. This feature permits overlay or inset applications to use the same runner.
Full length runners make installation in panel or face frame cabinets possible.
Load capacity
█ 100 lb static, 90 lb dynamic TANDEM plus BLUMOTION 563 series
TANDEM plus BLUMOTION 563 Series
Rear notching
Drawers must be notched in the back to
accommodate TANDEM runners.
Make the back panel shorter and extend the
drawer bottom to the back of the drawer.
Option - no notching
Dimensions
13 (1/2")
35 (1-3/8") min.
The notches must be flush with the drawer
sides and bottom.
rear
view
General specifications
