Charles McMurray Co. 2021 Catalog

398 / 1590

• Length 1118 (44-1/32") cut-to-size
• Maximum cabinet width = 1400 (55")
• Recommended for all cabinet widths greater than 350 (14")
Item No. List Ea.
$14.56
• To be used with the optional synchronization rod
• Two needed per application
Item No. List Ea.
$0.94
TIP-ON BLUMOTION for MOVENTO
Front Gap Template
For creating a 3.5 (1/8") front gap
Item No. List Ea.
$21.80
1 MOVENTO Slides
Synchronization Adapter (2 included with TIP-ON kit)
Synchronization Rods
3 TIP-ON Kits
Item No.
Drawer
Length
For Overall
Cabinet Depth
List Pr.
6
Standard-Duty - 125 lb. static load capacity
305 (12") 381 (15") $61.48
381 (15") 457 (18") $61.48
457 (18") 533 (21") $61.48
533 (21") 610 (24") $62.14
305 (12") 381 (15") $60.28
381 (15") 457 (18") $60.28
457 (18") 533 (21") $60.28
533 (21") 610 (24") $60.94
Heavy-Duty - 170 lb. static load capacity
457 (18") 533 (21") $77.38
533 (21") 610 (24") $78.10
610 (24") 686 (27") $89.56
686 (27") 762 (30") $93.38
762 (30") 838 (33") $104.88
2 Locking Devices
• Enables MOVENTO drawers to be opened with just
a light touch of the drawer front
• Same installation dimensions as MOVENTO
• Fully mechanical motion
• Smooth running action
• Four-dimensional adjustment
• Load capacity of runner remains unchanged
• Can be used with or without pulls
Order MOVENTO slides, locking devices
and TIP-ON kit separately.
For cabinet widths greater than 350mm order
a synchronization rod .
Includes left and right TIP-ON units &
triggers and2 synchronizationadapters.
Item No.
For
Length List Set
For up to 44 lbs.
12" only $49.88
15-21" $49.88
For 44-88 lbs.
15-21" $49.88
For 88-155 lbs.
18-30" $49.88
For narrow applications:
• Length 64 (2-1/2") cut-to-size
• Opening Width: Maximum 305 (12")
Minimum 281 (11-1/16")
NOTE: Order BT51.0501.20 narrow drawer locking devices
Item No. List Ea.
$3.18
1 3
2 4
Rod length = opening width
minus 267 (10-1/2")
Rod length = opening width
minus 241 (9-1/2")
100 pair per box, sold per pair.
Item No. Description List Pair
Standard $8.00
Vertical Mount $11.28
Narrow Drawer $11.08
4
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 2021 1946 398 Prices subject to change without notice.
