MOVENTO 763H & 763. (SHORT) Drawer Slides
Maximum Material = 5/8"
Full Extension, BLUMOTION Soft-Closing, 125 lb. Capacity
Basic Components
locking
device runner
Item No.
Drawer
Length Runner Length
Face Frame w/Rear Bkts
Box List Pair
List Pair
6 Minimum Maximum
305 (12") 319 (12-9/16") 328 (12-29/32") 370 (14-9/16") 6 $68.18 $61.48
381 (15") 395 (15-9/16") 404 (15-29/32") 446 (17-9/16") 6 $68.18 $61.48
457 (18") 471 (18-17/32") 480 (18-29/32") 522 (20-9/16") 6 $68.18 $61.48
533 (21") 548 (21-9/16") 557 (21-15/16") 599 (23-19/32") 6 $68.92 $62.14
Rear Mounting Bracket for Frame Cabinets
For use when installing MOVENTO runners in face frame cabinets.
• Not for use with SHORT version or heavy-duty slides
• Not for use with TIP-ON BLUMOTION
• One pair required per drawer
• Depth and lateral self-alignment
• Zinc-coated steel
Item No. Box List Pair
List Pair
50
B2953750 50 pr $4.06 $3.24
Standard Locking Devices - sold per pair
Item No. Box List Pair
BT51.7601 100 pr $8.00
See page 464 for other options.
Screws
Item No. Description List c
For slides #7 x 5/8" FHPH $7.94
B612TH100 For locking devices #6 x 1/2" Trusshead
(4 needed per pair.) $11.48
Locking device spacer for sub-fronts 12 mm
(15/32") & 13 mm (1/2") only.
Item No. Box List Ea.
List Ea.
40
BT59.K010M 40 $1.64 $1.38
SHORT STYLE
Item No.
Drawer
Length Runner Length
Minimum Inside
Cabinet Depth Box List Pr.
List Pr.
6
305 (12") 316 (12-7/16") 325 (12-13/16") 6 $66.84 $60.28
381 (15") 392 (15-7/16") 401 (15-13/16") 6 $66.84 $60.28
457 (18") 468 (18-7/16") 477 (18-13/16") 6 $66.84 $60.28
533 (21") 544 (21-7/16") 553 (21-13/16") 6 $67.58 $60.94
Maximum drawer thickness is 16 mm (5/8").
Order slides, locking devices
and screws separately.
NOTE: For frame applications use a minimum
of three screws per bracket.
