Charles McMurray Co. 2021 Catalog

248h / 1590

Face Frame Mounting Plates
Cam Screw-On
• Attach with #8 x 3/4" trusshead screws
• Hole spacing 40 mm
• Cam height adjustment ±2 mm
• Zinc die-cast, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
HT9090882 0 mm $3.08 $2.90 $2.60
HT9090884 4.5 mm $3.26 $3.08 $2.76
04/22
Screw-On
Pre-Mounted Euro Screws
• Hole spacing 32 mm
• Height adjustment with oblong holes
• Steel, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
0 mm $1.22 $1.14 $1.02
1.5 mm $1.14 $1.08 $0.96
3 mm $1.38 $1.30 $1.16
5 mm $1.88 $1.76 $1.58
Wing Mounting Plates
• Hole spacing 32 mm
• Height adjustment with oblong holes
• Steel, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
0 mm $0.86 $0.82 $0.72
1.5 mm $1.08 $1.02 $0.92
3 mm $1.22 $1.14 $1.02
5 mm $1.40 $1.32 $1.20
Screw-On
• Hole spacing 40 mm
• Height adjustment with oblong holes
• Zinc, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
930 0 mm $2.26 $2.14 $1.92
1.5 mm $2.28 $2.14 $1.92
4.5 mm $2.48 $2.34 $2.10
Screws - Trusshead Phillips
Face frame mounting plates use #8 x 3/4"
wood screws.
