Charles McMurray Co. 2021 Catalog

248i / 1590

Accessories
Insertion Ram
Spacers
Opening Angle Restrictors
Item No. List Ea.
$240.59
Insertion ram for Sensys hinges.
Opening angle restrictor for Sensys
110° hinges.
Opening angle restrictor for Sensys
165° hinges.
Screw-On
• Increases spacing by max. 22 mm
• Includes fixing screw
• Zinc, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
8 mm $4.66 $4.38 $3.94
12 mm $5.46 $5.16 $4.64
22 mm $5.22 $4.92 $4.42
• For 20 x 32 mm holes
• Hole spacing 32 mm
• Height adjustment ±2 mm
• Steel, nickel plated
Item No. Height List Ea.
List Ea.
50
List Ea.
200
1.5 mm $4.70 $4.42 $3.98
75096 3 mm $3.56 $3.36 $3.02
In-Line Mounting Plates
• Restrict angle from 110° to 85°
Item No. List Ea. List Ea. 50 List Ea. 200
$0.28 $0.26 $0.22
• Restrict angle from 165° to 105° or 120°
Item No. List Ea. List Ea. 50 List Ea. 200
$0.48 $0.46 $0.40 11/21
Inset Plate - Screw-On
• Use with half overlay hinge
• Attach with #8 x 3/4" trusshead screws
• Cam height adjustment ±1.6 mm
• Zinc die-cast, nickel plated
Item No. Height List Ea.
List Ea.
100
List Ea.
400
HT9179885 3 mm $11.16 $10.54 $9.46
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 248i Prices subject to change without notice.
