50° / 65° Opening Angle Hinges For Corner Cabinet Folding Doors

• Cup diameter 35mm

• Cup depth 12.8mm

• Diagonal adjustment + 9.5 mm / -9.5 mm

• Integrated overlay & depth adjustment - see diagrams

• Height adjustment at mounting plate

• Zinc die-cast and nickel-plated steel

Overlay Hinges

Item No. Description

List Ea.

HT9090115

Screw-on

$14.22

HT9090116

Press-in

$13.82

HT9090119

Fix Fast

$17.16

VERSION A - cup drill holes in one door

• All cup drillings in one door

• Hairline reveal can be provided between door units

• No cutaway in cup holes necessary

• Same door width for both elements

• Diagonal adjustment capability for easy adjustment to door thickness

• Same cup distance on both sides of side mounted door

• Hole line distance of 37mm in the folding door panel

• For door thickness 16 - 21mm

• Cup distance C 3 - 6mm

VERSION B - cup drill holes in both doors

• Both door units are the same

• No cutaway in cup holes necessary

• Diagonal adjustment capability for easy adjustment to door thickness

• Hole line distance of 41 mm in the folding door panel

• For door thickness 16 - 21 mm

• Cup distance C 3 - 6 mm

Calculation of door width

Calculation of mounting plate distance

Door width = cabinet width - reveal F - door thickness

Door width = cabinet width - reveal F - door thickness - 5 mm

For cup distance C = 4.5 mm: Distance D = 0 mm

For cup distance C = 3.0 mm: Distance D = 1.5 mm

Differing cup distances can be evened out by depth and diagonal

adjustment capability.

For cup distance C = 4.5 mm: Distance D = 0 mm

For cup distance C = 3.0 mm: Distance D = 1.5 mm

Differing cup distances can be evened out by depth and diagonal

adjustment capability.
