510x / 1645
09/24
Hawa Concepta III 35
Sliding Cabinet Door System
for Push-to-Open or Pull-to-Open
Wood Doors up to 77 Lbs.
III
35
• Door height: 1900 mm - 2700 mm (74-13/16" to 106-5/16")
• Door weight: 22 to 77 lbs.
• Door width: 440 mm - 750 mm (17-5/16" to 29-1/2")
• Door thickness: 18-26 mm (3/4" to 1")
• Doors pivot 90° and slide fully into cabinet
• Uniform, flush front design with even gap pattern
• Handed hardware for (1) pivoting/lateral
push-to-open
(handleless) or
pull-to-open
(with handle)
slide-in door
• Optional exterior cabinet connector (order separately for partial overlay application)
Hardware Set
4 4
Hinge slot nut,
plastic
33" LH top
running track,
aluminum
1
1 1
Height adj.
hinge mounting
plate, nickel-
plated
Adjusting
tool set
1 1
4 4
Concealed
hinge w/soft-
close, nickel-
plated
33" RH
bottom
guide track,
aluminum
1
2 2
28-3/4" profile
for magnetic
guide (w/
double-sided
tape)
33" RH top
running track,
aluminum
1
1
33" LH bottom
guide track,
aluminum
Mounting hardware included
Push Slide-in Set
LH push
slide-in unit
1
End-stop
bracket for
Push ejector,
zinc-plated
1 1
Push ejector,
plastic
1 1
Push-to-open
w/adaptor
plate, plastic
1 1
Push cover
cap set for
stops, plastic
1 1
RH push
slide-in unit
1
Pull Slide-in Set
LH pull
slide-in
unit
1
End-stop
bracket
pull, zinc-
plated
1 1
Soft-close
mechanism
w/ end-
stop
1 1
Pull cover
cap set
for stops,
plastic
1 1
RH pull
slide-in
unit
1
See next pg. for specs
Sold per kit, order one kit per door.
Set No.
Description
List Set
HW-CONCEPTA3-35PS-LHardware Set Left
$3,217.92
HW-CONCEPTA3-35PS-RHardware Set Right $3,217.92
Sold per kit, order one kit per door.
Set No.
Description
List Set
HW-CONCEPTA3-35PL-LHardware Set Left
$2,691.52
HW-CONCEPTA3-35PL-RHardware Set Right $2,691.52
Kit (handed) includes:
Hardware set, slide-in set and
upright profile. Order exterior
cabinet connector separately.
Kit (handed) includes:
Hardware set, slide-in set and
upright profile. Order exterior
cabinet connector separately.
Push-to-Open
Pull-to-Open
LH RH
LH RH
Exterior connector (optional):
For partial overlay application
on freestanding cabinets. 55 mm (2-3/16") x 560 mm (22-1/16").
Sold per set, order one set per door.
Item No.
List Ea.
HW-CONCEPTA3-31005 $288.16
Upright Profile
Upright profile,
aluminum, 97-7/16" 1
