Charles McMurray Co. 2023 Catalog

510aa / 1645

09/24
Hawa Folding Concepta III 20
Sliding Cabinet Door System for 2 Wood Doors up to 44 Lbs.
Push-to-Open or Pull-to-Open
III 20
• Door height: 1200 mm - 2200 mm (47-1/4" to 86-5/8")
• Door weight: 13 to 44 lbs.
• Door width: 440 mm - 750 mm (17-5/16" to 29-1/2")
• Door thickness: 18-26 mm (3/4" to 1")
• Folding doors pivot and slide fully into cabinet
• Uniform, flush front design with even gap pattern
• Handed hardware for (1) pivoting/folding lateral
push-to-open (handleless) or pull-to-open (with handle)
slide-in door, black or mill finish
• Optional aluminum base profiles (order separately for
overlay application)
Push Slide-in Set
LH push
slide-in unit 1
End-stop
bracket for
Push ejector,
zinc-plated
1 1
Push ejector,
plastic 1 1
Slide-in
securing
mechanism,
plastic
1 1
Adhesive
plate with
double-sided
tape
1 1
RH push
slide-in unit 1
Pull Slide-in Set
LH pull
slide-in unit 1
End-stop
bracket
pull, zinc-
plated
1 1
Slide-in
securing
mechanism,
plastic
1 1
RH pull
slide-in unit 1
See pg. 510ac for specs and track set components
Black or mill finish. Sold per kit, order one kit per (2) doors.
Set No. Description List Set
Mill Finish
Hardware Set Left $5,274.18
Hardware Set Right $5,274.18
Black
Hardware Set Left $5,644.82
Hardware Set Right $5,644.82
Black or mill finish. Sold per kit, order one kit per (2) doors.
Set No. Description List Set
Mill Finish
Hardware Set Left $4,490.98
Hardware Set Right $4,490.98
Black
Hardware Set Left $4,861.62
Hardware Set Right $4,861.62
Kit (handed) includes:
Hardware set, slide-in set, track
set and upright profile set. Order base profile set separately.
Kit (handed) includes:
Hardware set, slide-in set, track
set and upright profile set. Order base profile set separately.
Push-to-Open Pull-to-Open LH RH LH RH
Base profile set (optional):
For overlay application. Sold per set,
order one set per (2) doors.
Item No. List Ea.
$402.02
Hardware Set*
4 Hinge slot nut,
plastic
Soft-close
mechanism 1
Push Set Only
1
Height adj. hinge
mounting plate,
nickel-plated
Push-to-open 1
4
Spring loaded
concealed hinge
w/soft-close,
nickel-plated
Push-to-open
counterplate,
plastic
1
4
Center concealed
hinge, matte
nickel-plated
Soft-close
mechanism 1
Pull Set Only
1 Running gear,
nickel-plated
Adj. stop
buffer, plastic 1
1 Running gear
hinge
Adjusting tool
set 1
*Mountinghardware and all components included inPush-to-
Open and Pull-to-Open sets, except where indicated.
Upright Profile Set
Upright profile,
aluminum, 77-3/4" 1
Door joint cover
panel, aluminum,
86-5/8"
1
Cover panel
retaining clip,
plastic, set of 6
1
All components included in Push-
to-Open and Pull-to-Open sets.
