Hardware depth calculation
T1 16-5/16"
T1 TB + 3-5/8" + Z3 - M
E1 TB - M
M ≥S + 5/8"
≤TB - 1-5/8"
Door Width
17-5/16" 19-11/16" 21-11/16" 23-5/8"
25-5/8"
27-9/16" 29-9/16"
86-5/8"
55
55
55
55
55
55
53
84-11/16"
55
55
55
55
55
55
51
82-11/16"
55
55
55
55
55
53
51
80-3/4"
55
55
55
55
55
53
49
78-3/4"
55
55
55
55
55
51
46
76-13/16"
55
55
55
55
53
49
46
74-13/16"
55
55
55
55
51
46
44
72-7/8"
55
55
55
53
49
46
42
70-7/8"
55
55
55
51
46
44
42
68-15/16"
55
55
55
49
46
42
40
66-15/16"
55
55
53
49
44
42
37
65"
55
55
51
46
42
40
37
63"
55
53
49
44
40
37
35
61-1/16"
55
51
46
42
40
35
33
59-1/16"
53
49
44
40
37
35
33
57-1/8"
51
46
42
37
35
33
31
55-1/8"
49
44
40
37
33
31
29
53-3/16"
46
42
37
35
33
31
29
51-3/16"
44
40
35
33
31
29
26
49-1/4"
42
37
33
31
29
26
24
47-1/4"
40
35
33
29
26
24
24
Door Height
Weight and door size calculations
Max. weight must be adapted
depending on the door size ratio.
Door flush with outer face
Protruding door
04/24
III
25
Hawa Concepta III
Sliding Cabinet Door System
up to 55 Lbs.
