510s / 1645
Order hardware set, profiles and accessories separately.
Handed, sold per set. Order one set per pair of doors.
Set No.
Description
List Set
HW-FCONCEPTA-27638Hawa Folding Concepta 25 Hardware Set Left $3,682.14
HW-FCONCEPTA-27639Hawa Folding Concepta 25 Hardware Set Right $3,682.14
See next pg. for profiles, accessories and specs
02/24
Hawa Folding Concepta 25
Sliding Cabinet Door System for 2 or 4 Wood Doors
• Door height: 1851 mm - 2600 mm (72-7/8" to 102-3/8")
• Door weight: 55 lbs. per door
• Door width: 300 mm - 700 mm (11-3/16" to 27-9/16")
• Door thickness: 19-26 mm (3/4" to 1-1/16")
• Folding doors pivot and slide fully into cabinet with no protrusion
• All components screw on
• Hardware for (1) pair pivoting/folding lateral slide-in doors
• Optional aluminum base & reinforcement profiles (order separately)
Hardware Set
1 1 Scissor action, complete,
59-1/16", steel
1
Interior connector,
bottom left,
25-7/16", aluminum
1 1 Rattle-proof upright
guide w/plastic rollers
1 1 Height-adjustable 2-wheel
running gear, zinc-plated
1
Interior connector, top
left, 25-7/16", aluminum
1 1
Depth adjustable end-
stop cover cap, top left/
bottom right
1 1 1-wheel folding door
running gear, nickel-plated
1 1
Exterior connector,
bottom right/top left,
25-7/16", aluminum
1 1
Depth adjustable end-
stop cover cap, top
right/bottom left
1 1 Concealed press-fit cup,
nickel-plated
1 1
Exterior connector,
bottom left/top right,
25-7/16", aluminum
1 1 Cover plates, 1 pr.,
stainless steel
1 1 Concealed 4-pc. hinge w/
damper, nickel-plated
1
Running track, left,
29-7/16", aluminum
1 1 Adjustable stop bumper,
plastic
1 1 Concealed 4-pc. center
hinge, steel
1
Bottom guide channel,
left, 29-7/16", aluminum
1 1 Allen key w/handle,
1/8" (3 mm)
1
Rear scissor bearing, left,
steel
1
Running track w/left-
hand curve piece,
55-15/16", aluminum
1 Rear scissor bearing,
right, steel
1 1 Rear scissor guide,
aluminum
1 1 4-pc. running track
adapter, plastic
1
Interior connector,
bottom right,
25-7/16", aluminum
1 1 Front scissor guide,
aluminum
1 1 3-pc. brush guide set,
plastic
1
Interior connector,
top right, 25-7/16",
aluminum
1 1 Upright, 98-7/16",
aluminum
1 1 Door clearance covering
screen, aluminum
1 Running track, right,
29-7/16", aluminum
1 1
Connecting profile, bottom
left/top right, 19-11/16",
aluminum
1 1
End position soft-close
system w/cover caps,
plastic
1
Bottom guide channel,
right, 29-7/16",
aluminum
1 1
Connecting profile, bottom
right/top left, 19-11/16",
aluminum
1 1 Pivot door damper,
plastic
1
Running track w/
right-hand curve piece,
aluminum
Order one hardware set per pair of doors, mounting hardware included.
May be combined with Hawa Concepta to create 2- and 4-leaf front panels without separating walls.
