Charles McMurray Co. 2023 Catalog

510n / 1645

02/24
Hawa Concepta 50
Sliding Cabinet Door System for Wood Doors
up to 110 Lbs.
• Door height: 2301 mm - 2850 mm (90-5/8" to 112-1/4")
• Door weight: 55 to 110 lbs.
• Door width: 300 mm - 900 mm (11-3/16" to 35-7/16")
• Door thickness: 19-50 mm (3/4" to 2")
• Doors pivot 90° and slide fully into cabinet with no protrusion
• All components screw to the intermediate panel
• Hardware for (1) pivoting/lateral slide-in door
• Integrated soft-closing mechanism and hinges
• Optional aluminum connecting profiles (order separately)
Hardware Set
1 Upright, 108-11/16",aluminum 1
Running track,
35-5/16",
pre-drilled aluminum
1
2-wheel, height
adjustable running
gear w/torsion plate,
zinc-plated
1
Bottom guide channel,
35-5/16", pre-drilled
aluminum
1 Rattle-proof uprightguide w/plastic rollers 1
Depth adjustable stop
cover cap, top left/
bottom right
1
Scissor action,
complete, 48-1/16",
steel
1
Depth adjustable stop
cover cap, top right/
bottom left
1 Front scissor guide,aluminum 1 Cover plates, stainlesssteel, 1 pr.
1 Rear scissor guide,aluminum 1 Stop damper w/retaining bracket
1 Rear scissor bearing,2-3/16", steel 1
Door retractor 25/50
w/damper, black
plastic
1
Concealed 5-pc. hinge
w/damper, nickel-
plated
1
End position soft-close
system w/cover caps,
black plastic
1
Spacer profile,
33-7/8", pre-drilled,
plastic
1 Allen key w/handle,1/8" (3 mm)
1 3-pc. brush guide set,plastic 1 Installation aid, plastic
Mounting hardware included See next pg. for specs
Order hardware set, connecting profiles and accessories separately.
Sold per set, order one set per door.
Set No. Description List Set
Hawa Concepta 50 Hardware Set $2,444.80
Door straightener recommended, see catalog pg. 788 for options
May be combined with Hawa Folding Concepta to create three-leaf front panels without separating walls.
Connecting Profiles
25-5/8" or 35-7/16"
cabinet connector
(2-3/16"), aluminum
Sold per each. Order two per door,
mounting hardware included.
Item No. List Ea.
$119.98
$159.64
For further information
on Hawa Concepta 50
visit:
Accessories
Concealed hinge w/soft-close, nickel-
plated. Sold per each.
$112.98
Spring-detent end-stop catch.
Sold per each.
$10.74
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 510n Prices subject to change without notice.
