Connecting Profiles
25-5/8" or 35-7/16"
cabinet connector
(2-3/16"), aluminum
Sold per each. Order two per door,
mounting hardware included.
Item No. List Ea.
$119.98
$159.64
02/24
Hawa Concepta 40
Sliding Cabinet Door System for Wood Doors
up to 88 Lbs.
• Door height: 1851 mm - 2500 mm (72-7/8" to 98-7/16")
• Door weight: 44 to 88 lbs.
• Door width: 300 mm - 900 mm (11-13/16" to 35-7/16")
• Door thickness: 19-50 mm (3/4" to 2")
• Doors pivot 90° and slide fully into cabinet with no protrusion
• All components screw to the intermediate panel
• Hardware for (1) pivoting/lateral slide-in door
• Integrated soft-closing mechanism and hinges
• Optional aluminum connecting profiles (order separately)
Hardware Set
1 Upright, 98-7/16",aluminum 1
Running track,
35-5/16", pre-drilled
aluminum
1
2-wheel, height
adjustable running
gear w/torsion plate,
zinc-plated
1
Bottom guide channel,
59-5/16", pre-drilled
aluminum
1 Rattle-proof uprightguide w/plastic rollers 1
Depth adjustable stop
cover cap, top left/
bottom right
1
Scissor action,
complete, 48-1/16",
steel
1
Depth adjustable stop
cover cap, top right/
bottom left
1 Front scissor guide,aluminum 1 Cover plates, stainlesssteel, 1 pr.
1 Rear scissor guide,aluminum 1 Stop damper w/retaining bracket
1 Rear scissor bearing,2-3/16", steel 1 Door retractor 30/40w/damper, plastic
1
Concealed 4-pc. hinge
w/damper, nickel-
plated
1
End position soft-close
system w/cover caps,
plastic
1
Spacer profile,
57-7/8", pre-drilled,
plastic
1 Allen key w/handle,1/8" (3 mm)
1 3-pc. brush guide set,plastic 1 Installation aid, plastic
Mounting hardware included
May be combined with Hawa Folding Concepta to create three-leaf front panels without separating walls.
Order hardware set, connecting profiles and accessories separately.
Sold per set, order one set per door.
Set No. Description List Set
Hawa Concepta 40 Hardware Set $2,323.72
Door straightener recommended, see catalog pg. 788 for options
See pg. 510o for specs
For further information
on Hawa Concepta 40
visit:
Accessories
Concealed hinge w/soft-close, nickel-
plated. Sold per each.
$112.98
Spring-detent end-stop catch.
Sold per each.
$10.74
