Charles McMurray Co. 2023 Catalog

02/24

Hawa Concepta 25

Sliding Cabinet Door System for Wood Doors

up to 55 Lbs.

Connecting Profiles

25-5/8" or 35-7/16"

cabinet connector

(2-3/16"), aluminum

Sold per each. Order two per door,

mounting hardware included.

Item No.

List Ea.

HW-CONCEPTA-CP25

$119.98

HW-CONCEPTA-CP35

$159.64

Accessories

Concealed hinge w/soft-close, nickel-

plated. Sold per each.

HW-CONCEPTA-27652

$112.98

Spring-detent end-stop catch.

Sold per each.

HW-CONCEPTA-27702

$10.74

Order hardware set, connecting profiles and accessories separately.

Sold per set, order one set per door.

Set No.

Description

List Set

HW-CONCEPTA-25

Hawa Concepta 25 Hardware Set

$1,661.10

Door straightener recommended, see catalog pg. 788 for options

• Door height: 1250 mm - 1850 mm (49-1/4" to 72-7/8")

• Door weight: 22 to 55 lbs.

• Door width: 300 mm - 750 mm (11-13/16" to 29-9/16")

• Door thickness: 19-50 mm (3/4" to 2")

• Doors pivot 90° and slide fully into cabinet with no protrusion

• All components screw to the intermediate panel

• Hardware for (1) pivoting/lateral slide-in door

• Integrated soft-closing mechanism and hinges

• Optional aluminum connecting profiles (order separately)

Hardware Set

1 Upright, 70-7/8",

aluminum

Depth adjustable stop

cover cap, top left/

bottom right

2 Rattle-proof upright

guide w/plastic rollers

Depth adjustable stop

cover cap, top right/

bottom left

1 Torsion plate

1 Cover plates, 1 pr.,

stainless steel

Scissor action,

complete, 35-7/16",

steel

Bottom guide channel,

52-11/16", pre-drilled

aluminum

1 Front scissor guide,

aluminum

1 Stop damper w/

retaining bracket

1 Rear scissor guide,

aluminum

1 Door retractor 25/50

w/damper, plastic

1 Rear scissor bearing,

2-3/16", steel

End position soft-close

system w/cover caps,

plastic

Concealed 3-pc. hinge

w/damper, nickel-

plated

1 Allen key w/handle,

1/8" (3 mm)

Spacer profile,

33-7/8", pre-drilled,

plastic

1 Installation aid, plastic

1 3-pc. brush guide set,

plastic

Mounting hardware included

May be combined with Hawa Folding Concepta to create three-leaf front panels without separating walls.

See pg. 510o for specs

For further information

on Hawa Concepta 25

visit:

bit.ly/498OPwc
