Charles McMurray Co. 2023 Catalog

510g / 1645

02/24
Hawa Clipo 36 H Inslide
Sliding Bypass Cabinet Door System
for Wood Doors
• Maximum door height: 2200 mm (86-5/8")
• Maximum door weight: 79 lbs.
• Maximum door width: 1000 mm (39-3/8")
• Door thickness: 19-25 mm (3/4" to 1")
• Self-closing clip-on system with height adjustment
• Hardware for (2) top-running bypass doors
• Screw-on or groove mounted aluminum track (order separately)
• Optional soft-close (order separately)
Hardware Set
4 Running gear,(2) left/(2) right
4 End stop, plastic
4 Running gearhousing, plastic
1 Door follower,plastic
1 Door followeradapter, steel
2 Bottom guide,plastic
Mounting hardware included
Soft-Close SC33 SC57 SC88
Soft-close
(Up to 33 lb.
load rating)
2
Soft-close
release 2 2 2
Soft-close
(Up to 57 lb.
load rating)
2
Soft-close
(Up to 88 lb.
load rating)
2
See next pg. for specs
Order hardware set, track and soft-close separately.
Set No. Description List Set
Hawa Clipo 36 H Inslide Hardware Set $320.24
Track: 2500 mm (98-7/16"), sold per each. Mounting hardware not included.
Item No. Description List Ea.
Single Running Upper Track $75.04
Double Running Upper Track $130.18
Lower Guide Rail $38.62
Track
2500 mm (98-7/16")
single running,
glue-on, aluminum
2500 mm (98-7/16")
double running (for door
thickness 1"), screw-on,
aluminum
2500 mm (98-7/16")
lower guide, glue-on,
plastic
For further information
on Hawa Clipo 36 H IS
visit:
Soft-Close: Sold per set. Order one set per door for soft-close/soft-open.
Mounting hardware included.
Set No. Description List Set
Up to 33 lb. load rating $109.46
Up to 57 lb. load rating $109.46
Up to 88 lb. load rating $109.46
