TANDEMBOX - D Height (8-1/8") w/Single Gallery - Gray Finish
100 lbs. Dynamic Load Rating
Sold per kit (components are also available individually).
Each kit includes:
1 pair Drawer Profiles 1 pair Top Gallery Rails
1 pair Cabinet Profiles 1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets
BZRG Top
Gallery Rails
Drawer Height: 207mm (8-1/8").
MinimumOpeningHeight: 228 (8-15/16") basedon3mm(1/8") clearance.
Minimum depth = actual profile length +3mm (1/8").
Interior Roll-out Drawers w/Gallery Single Gallery Drawers
Sold per kit (components are also available individually).
Each kit includes:
1 pair Drawer Profiles 1 each Cross Rail
1 pair Cabinet Profiles 1 pair Top Gallery Rails
1 pair Rear Fixing Brackets 1 pair Interior Front Brackets
Front piece must be ordered separately (BZ31L1036).
Drawer Height: 207mm (8-1/8").
MinimumOpeningHeight: 228 (8-15/16") based on 3mm(1/8") clearance.
Minimum depth = actual profile length +3mm (1/8").
For a complete list of components
see catalog pages 455-456.
Complete specifications are
available at
Recommended Fasteners
Slides: #7x5/8" flathead (MCFPT587)
Rear Brackets: #6 x 1/2" trusshead
NOTE: Some sizes require a lead-time.
Cross Gallery Rail
42", cut-to-size
L=opening
width minus
122 (4-13/16")
(avail. in
4 sizes)
Kit No.
Nominal
Length
Actual
Length List Per Kit
100 lb. Load Rating
16" 15-3/4" $106.06
TB-D-450G 18" 17-11/16" $121.30
20" 19-11/16" $107.78
22" 21-5/8" $112.74
Kit No.
Nominal
Length
Actual
Length List Per Kit
100 lb. Load Rating
16" 15-3/4" $148.44
18" 17-11/16" $148.32
20" 19-11/16" $150.16
22" 21-5/8" $155.12
03/23
BZ30D Rear Fixing
Bracket Set B378M Drawer Profile Set
B578 Cabinet Profile Set
Item No. Description List
Interior Drawer Parts
Interior front fixing bracket $22.68 pr
Front piece $53.74 ea
Cross Gallery Rail $26.34 ea
Fixing Brackets List Pair
Rear fixing bracket $5.98
INSERTA front fixing brkt $3.32
Standard Drawer Components Interior Roll-out Components
Front Fixing Bracket Interior Front Bracket Set
1036mm (40-13/16")
cut-to-size L=inside cabinet
width minus 132 (5-3/16")
BZ31L1036A Front Piece
(Required for interior roll-out.)
Not included in kit, order separately.
