Charles McMurray Co. 2023 Catalog

452 / 1645

TANDEMBOX - M Height (3-5/16") - Gray Finish
100 lbs. Dynamic Load Rating
Sold per kit (components also available individually).
Each kit includes:
1 pair Drawer Profiles
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets
Sold per kit (components also available individually).
Each kit includes:
1 pair Drawer Profiles
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
1 pair Interior Front Brackets
Front piece must be ordered separately (BZ31L1036).
Interior Roll-out Drawers Standard Drawers
Recommended Fasteners
Slides: #7x5/8" flathead (MCFPT587)
Rear Brackets: #6 x 1/2" trusshead
NOTE: Some sizes require a lead-time.
For a complete list of components
see catalog pages 455-456.
Drawer Height: 84mm (3-5/16").
Minimum Opening Height: 98.5mm (3-7/8") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Drawer Height: 84mm (3-5/16").
Minimum Opening Height: 136.5mm (5-3/8") based on 3mm (1/8")
clearance. With handle application 106mm (4-3/16").
Minimum depth = actual profile length +3mm (1/8").
Complete specifications are
available at
03/23
BZ30M Rear Fixing
Bracket Set B378M Drawer Profile Set
B578 Cabinet Profile Set
Item No. Description List
Interior Drawer Parts
Interior front fixing bracket $22.68 pr
Front piece $53.74 ea
Fixing Brackets Price pr.
Rear fixing bracket $5.98
INSERTA front fixing bracket $3.32
Standard Drawer Components
Front Fixing Bracket
BZIF71 gray
Interior Front Bracket Set
1036mm (40-13/16") cut-to-size
L=inside cabinet width minus
132 (5-3/16")
BZ31L1036A Front Piece
(Required for interior roll-out.)
Not included in kit, order separately.
Interior Roll-out Components
Kit No.
Nominal
Length
Actual
Length List Per Kit
100 lb. Load Rating
16" 15-3/4" $85.38
18" 17-11/16" $85.46
20" 19-11/16" $86.06
22" 21-5/8" $91.38
Kit No.
Nominal
Length
Actual
Length List Per Kit
100 lb. Load Rating
16" 15-3/4" $96.78
18" 17-11/16" $96.86
20" 19-11/16" $97.46
22" 21-5/8" $102.78
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 452 Prices subject to change without notice.
