Charles McMurray Co. 2023 Catalog

397 / 1645

MOVENTO Slides
• Length 1118 (44-1/32") cut-to-size
• Maximum cabinet width = 1400 (55")
• Recommended for all cabinet widths greater than 350 (14")
Item No. List Ea.
$14.56
• To be used with the optional synchronization rod
• Two needed per application
Item No. List Ea.
$0.94
Front Gap Template
For creating a 3.5 (1/8") front gap
Item No. List Ea.
$21.80
Synchronization Adapter
(2 included with TIP-ON BLUMOTION kit)
Synchronization Rods
TIP-ON BLUMOTION Kits
Item No.
Drawer
Length
For Overall
Cabinet Depth List Pair
Standard-Duty - 125 lb. static load rating
305 (12") 381 (15") $68.18
381 (15") 457 (18") $68.18
457 (18") 533 (21") $68.18
533 (21") 610 (24") $68.92
305 (12") 381 (15") $66.84
381 (15") 457 (18") $66.84
457 (18") 533 (21") $66.84
533 (21") 610 (24") $67.58
Heavy-Duty - 170 lb. static load rating
457 (18") 533 (21") $89.06
533 (21") 610 (24") $89.88
610 (24") 686 (27") $103.08
686 (27") 762 (30") $107.46
762 (30") 838 (33") $120.72
Locking Devices
• Enables MOVENTO drawers to be opened with just
a light touch of the drawer front
• Same installation dimensions as MOVENTO
• Fully mechanical motion
• Smooth running action
• Four-dimensional adjustment
• Load capacity of runner remains unchanged
• Can be used with or without pulls
Order MOVENTO slides, locking devices
and TIP-ON BLUMOTION kit separately.
For cabinet widths greater than 350mm order
a synchronization rod .
Set No.
For
Length List Set
For up to 44 lbs.
12" only $49.88
15-21" $49.88
For 44-88 lbs.
15-21" $49.88
For 88-155 lbs.
18-30" $49.88
For narrow applications:
• Length 64 (2-1/2") cut-to-size
• Opening Width: Maximum 305 (12")
Minimum 281 (11-1/16")
NOTE: Order BT51.0501.20 narrow drawer locking devices
Item No. List Ea.
$3.18
1 3
2 4
Rod length = opening width
minus 267 (10-1/2")
Rod length = opening width
minus 241 (9-1/2")
100 pair per box, sold per pair.
Item No. Description List Pair
Standard $8.00
Vertical Mount $11.28
Narrow Drawer $11.08
TIP-ON BLUMOTION for MOVENTO
1
2
3
4
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 397 Prices subject to change without notice.
