C80 Series 45° Pivot-Pro
Soft-Close Angled Hinge
Door Thickness 5/8" to 1"
• Opening angle: 110°
• Snap-on, cam-adjustable
• Hinge cup depth: 7/16" (11.5 mm)
• Hinge cup diameter: 1-3/8" (35 mm)
• Possible drilling distance on door (B):
1/8" to 1/4" (3-6 mm)
B T= 14 15 16 17 18 19 20 21 22 23 24
3 R= 0.3 0.5 0.7 0.9 1.2 1.5 1.8 2.2 2.6 3.1 3.8
3 R= 0.3 0.5 0.7 0.9 1.1 1.4 1.7 2.1 2.5 3.0 3.5
3 R= 0.3 0.5 0.7 0.9 1.1 1.4 1.7 2.0 2.4 2.9 3.4
3 R= 0.3 0.5 0.6 0.8 1.1 1.3 1.6 2.0 2.3 2.8 3.2
3 R= 0.3 0.4 0.6 0.8 1.0 1.3 1.6 1.9 2.3 2.7 3.1
3 R= 0.3 0.4 0.6 0.8 1.0 1.3 1.5 1.9 2.2 2.6 3.0
T= Door thickness
B = Cup hole drilling distance from door edge
Space needed to open door
Space needed to open door
B T= 14 15 16 17 18 19 20 21 22 23 24
3 G= 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
3 G= 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.1
3 G= 0.0 0.0 0.0 0.0 0.1 0.3 0.4 0.6 0.8 1.0 1.1
3 G= 0.4 0.6 0.7 0.9 1.1 1.2 1.4 1.6 1.8 1.9 2.1
3 G= 1.4 1.5 1.7 1.9 2.1 2.2 2.4 2.6 2.8 2.9 3.1
3 G= 2.4 2.5 2.7 2.9 3.0 3.2 3.4 3.6 3.7 3.9 4.1
The above values are calculated for square edges. They are reduced if doors have radiused edges.
