C80 Series 155° Pivot-Pro Hinge
• Snap-on, cam-adjustable
• Available in soft-close and self-close
• Hinge cup depth: 7/16" (11.5 mm)
• Hinge cup diameter: 1-3/8" (35 mm)
• Possible drilling distance on door (B):
1/8" to 1/4" (3-6 mm)
B T= 16 17 18 19 20 21 22 23 24
3
R= 0
0
0
0
0
0
0
0
0
4
R= 0
0
0
0
0
0
0
0
0
5
R= 0
0
0
0
0
0
0
0
0
6
R= 0
0
0
0
0
0
0
0
0
T= Door thickness
B = Cup hole drilling distance from door edge
Space needed to open door
Door Projection
Full overlay C = 0
The door combined with a mounting plate H = 0, opens at
90° with a 2.3mm protrusion allowing objects (e.g. drawers)
to move from inside cabinet.
No gap is required when door thickness is less than 24mm.
Trial assembly recommended when door thickness is greater than 24mm.
