110° Thin Door Hinges
Overlay Hinges
Item No. Description
List
Ea. 50
Silent System (Soft-Close)
Screw-on $12.88
Press-in $14.28
Minimum Reveal Table
Door
Thickness
Cup Distance C
3 4 4.5 5 6 7
10 0.1 0.1 0.1 0.1 0.1 0.1
11 0.2 0.2 0.2 0.2 0.2 0.2
12 0.4 0.4 0.4 0.4 0.4 0.4
13 0.6 0.6 0.5 0.5 0.5 0.5
14 0.8 0.8 0.7 0.7 0.7 0.7
15 1.0 1.0 1.0 1.0 0.9 0.9
16 1.3 1.3 1.3 1.2 1.2 1.2
17 1.4 1.5 1.5 1.6 1.6 1.7
18 1.8 1.8 1.9 1.9 2.0 2.0
19 2.1 2.2 2.3 2.3 2.3 2.4
The table entries refer to doors with an edge
radius of 1 mm. On doors with other radii, the
minimum reveal changes as follows:
Radius 0 mm: Values shown in table + 0.3 mm
Overlay
Distance D = C + B - A
= cup distance C + 12.5 mm - overlay A
Full Overlay 0 mm
Mounting
Plate
Distance
Cup Distance C
3 4 4.5 5 6 7
10 mm 5.5 6.5 7.0 7.5 8.5 9.5
11 mm 4.5 5.5 6.0 6.5 7.5 8.5
12 mm 3.5 4.5 5.0 5.5 6.5 7.5
13 mm 2.5 3.5 4.0 4.5 5.5 6.5
14 mm 1.5 2.5 3.0 3.5 4.5 5.5
15 mm 0.5 1.5 2.0 2.5 3.5 4.5
16 mm 0.5 1.0 1.5 2.5 3.5
17 mm 0.0 0.5 1.5 2.5
18 mm 0.5 1.5
19 mm 0.5
Overlay
• For door thickness 10 - 19 mm
• Available in Silent System with self-closing feature
• Cup depth 7.8 mm
• Integrated overlay adjustment + 2mm / - 2 mm
• Integrated depth adjustment + 3 mm / - 2 mm
• Height adjustment at mounting plate
• Nickel-plated steel
Opening angle restrictor
for Sensys 110° hinges
(restricts angle
from 110° to 85°)
See pg. 244 for pricing
10/23
Protrusion/Installed Depth
Hinge protrusion H / door protrusion T for
distance D = 0 mm and cup distance C =
3 mm.
Door
Mounting
Option
H mm T mm
Full Overlay 25.0 8.5
DOOR
