Charles McMurray Co. 2021 Catalog

518 / 1590

.70"
.08" MAT'L
5.93"
.46"
KV8070, KV8071 Series
EZ Pivot Door Slides
Side Mount, 30 lb. Capacity per Door
• Cushioned stops & door hold-out
• Self-closing 3-way adjustable door hinge
• Precision steel ball-bearings
• Vertical or horizontal mounting
• Large follower strip mounting plate for
rigidity and installation ease
• Black finish
Maximum Door Dimensions: 24" x 42"
Polybagged 1 set per bag with screws, self-closing 35 mm inset
hinges & baseplates. 10 sets per box. Price is per set.
Item No. Size Travel
Min. Cabinet
Depth List Set
List Set
10
12" 8.46" 12-3/8" $116.76 $98.96
14" 10.46" 14-3/8" $118.68 $100.58
16" 12.46" 16-3/8" $120.48 $102.10
18" 13.46" 18-3/8" $122.16 $103.52
20" 15.46" 20-3/8" $124.16 $105.22
22" 17.46" 22-3/8" $125.96 $106.74
24" 19.46" 24-3/8" $136.12 $114.26
KV8070 - Includes hinges & baseplates
Polybagged 1 pair per bag with screws. 10 pair per box. Price is
per pair.
Item No. Size Travel
Min. Cabinet
Depth List Pr.
List Pr.
10
14" 10.46" 14-3/8" $96.30 $80.82
16" 12.46" 16-3/8" $98.08 $82.32
18" 13.46" 18-3/8" $99.84 $83.78
20" 15.46" 20-3/8" $100.68 $84.50
22" 17.46" 22-3/8" $102.18 $85.76
KV8071 - w/o hinges or baseplates
For Inset Application, 3/4" Thick Doors
Item No. Description List Kit
35 mm Self-Closing, Black $41.52
35 mm Free-Swing, Nickel $42.36
Item No. Description List Ea.
Free-Swinging Hinge $6.28
0 mm Baseplate, Zinc $2.20
For 1/4" Overlay Application, 3/4" Thick Doors
Item No. Description List Kit
40 mm Self-Closing $52.22
For Inset Application, Thick Doors (up to 1-1/4")
Item No. Description List Kit
40 mm Self-Closing $53.74
Hinge Kit Options
Salice black hinge kits include 2 hinges,
2 baseplates & screws
(order 1 kit per pair of slides)
Additional protection for raised panel doors.
Order 2 per pair of slides. Includes screws.
Item No. List Each List Each 20
$13.14 $10.90
Raised Panel Cassette Roller
Profile
approx. centerline
of door frame member
cassette roller
(picture shows 8091 slide)
NOTES:
For face frame applications you need to apply furring strips.
Not recommended for square doors or where door width is
greater than door height.
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $5.88
10c $38.60
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 2021 1946 518 Prices subject to change without notice.
