Charles McMurray Co. 2021 Catalog

513 / 1590

2500 per box, sold per each. Order screws separately (8/32
trusshead MC832X).
Item No.
Drilling
List Each
List Each
2500 A B
25 5 $2.32 $2.02
A B
System 10 - Drawer Front Adjuster
Drawer Front Adjuster
• Nylon housing with pre-mounted 8-32 steel nut
• For 4-sided drawers
• Adjusts height and side-to-side by 5 mm (3/16")
• Use 8-32 machine screw (not included) to install drawer front
• Drill 20 mm x 10.5 mm deep
• 1000 per box, sold per each
Item No. List Each
List Each
1000
$0.72 $0.62
Marking Gauge
(For Drawer Front Adjusters)
Used to transfer the center points of the drawer front adjuster
from the drawer front to the drawer box.
Item No. List Each
$12.24
Drawer Front Adjusting Screw
Washer Head, Combo Square Drive
Deep Thread, White Finish
Sold per hundred (c).
Item No. Size Box List c
List c
Full Box
#8x1-1/4 80c $16.76 $12.80
Drawer Front Adjusting Screw
Large washer-head screw, #8.
Type 17 screw tip for easy instal-
lation. To install: drill 5/16" hole
in drawer box, attach drawer
front, adjust drawer front and secure with adjusting screw, fix
drawer front with knob or pull screws. Sold per hundred (c).
Item No. Size Box List c
List c
Full Box
#8x1" 70c $8.98 $6.84
#8x1-1/8" 60c $8.16 $6.46
#8x1-1/4" 60c $10.46 $8.00
#8x1-1/2" 50c $12.82 $9.32
1. Pre-bore 20 mm holes in
drawer front and insert gauges.
2. Align the drawer front to make
marks in the drawer box.
3. Mark fixing positions with a
light tap on the drawer front.
4. Bore 5 mm (3/16") holes
through the drawer box.
1 2
3 4
• Multi-direction adjustment
• Locking screw to fasten
• Independent of drawer system
• Dark brown finish
• Screws not included
Boring/Drill Bits
Item No. Description List Ea.
3/16" Taper Drill Bit $21.14
20 mm RH Carbide Boring Bit $73.52
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 2021 1946 513 Prices subject to change without notice.
