Pivoting Pocket Door System for Vertical Mount Doors
BLACK - 75 lb. Load Rating
Hinges not included
(1 pair of slides needed per door)
• Anti-Rak cable system
• Maximum weight capacity 75 lbs.
• For door thickness: 3/4" to 1-1/4"
(For doors 13/16" or thicker order optional 40 mm hinge kit)
• For door heights: up to 78"
(For doors 36" to 78" tall order additional hinge carrier strip kits)
• For door widths: up to 26"
• Pocket width: 2" to 2-1/2" depending on door thickness
Door Height (E) Hinges
Required
36" - 46-61/64" 3
47" - 59" 4
59" - 71" 5
72" - 78-47/64" 6
Pair includes slide mounting hardware and instructions. Order hinges
kit separately (see below). 4 pair per box. Sold per pair.
Item No. Length Travel
List Pair
1
List Pair
4
14" 10-1/4" $315.10 $254.76
16" 12-1/2" $319.00 $257.92
18" 13-1/2" $377.18 $304.96
20" 15-1/2" $327.16 $264.52
22" 17-1/2" $331.10 $267.70
24" 19-1/2" $360.58 $291.54
32" 27-1/2" $508.76 $411.34
Hinge Kit Options
(includes 2 hinges, 2 plates, 2 spacers and screws)
Item No. Description Door Thickness List Kit
Inset Application
35 mm zinc 3/4" $92.48
40 mm zinc 13/16" to 1-1/4" $98.94
7/16" Overlay Application
40 mm zinc up to 3/4" $108.86
Hinge Carrier Strip Kit
Required for all doors 36" to 78" tall. Includes 2 carrier strips, 3
connector clips and screws.
Item No. Description List Kit
Black $68.58
NOTE: Order 2 hinge carrier strip kits per 2 doors for heights of 36" to
56", and 3 kits for doors 57" to 78".
Connector Clips (includes 1 clip and 4 screws)
Item No. Description List Ea.
Stainless Steel $6.80
NOTES: Use 1 connector clip at each joint of carrier strip and 1 for every
hinge mounted on the carrier strip. They are not required for the hinge
mounted directly to the slide.
For 2 doors 59" to 71" order 1 Connector Clip.
For 2 doors 71" to 78" order 3 Connector Clips.
