High strength nylon, natural color. Use with system screws or
#7 wood screws. Sold per each.
Item No. Width Box List Ea.
List Ea.
Full Box
13 mm (1/2") 1000 $1.00 $0.75
3 mm (1/8") 1000 $0.69 $0.51
19 mm (3/4") 1300 $1.94 $1.43
Drawer Slide Spacers
Universal Drawer Bracket
Zinc-coated steel bracket for mounting Blum runners on a cabinet
bottom (roll out tray). 4 brackets per set with 8 each M4x6 mm
screws to attach runners to bracket. Use screws to
attach bracket to cabinet. 10 sets per box, sold per set.
Item No. List Set
$14.26
For use with 230M and METABOX slides. Precise positioning of
cabinet profile screws.
Item No. List Ea.
$40.98
Drawer Slide Gun
Use 3 deep thread system
screws to attach
runner to spacer and
spacer to cabinet side
Dynamic Wear Test
100,000 open/close cy-
cles with a total weight
of 75 lbs. on a 22" drawer.
Static Loading Test
100 lbs. applied to a
half extended 22" draw-
er for 1 minute.
Side Pressure Test
A force of 33 lbs. is ap-
plied ten times to a fully
extended 22" drawer.
Testing Standards
NOTE: Use spacers on front, middle and rear of each cabinet
profile for adequate support. Other spacers can be found on
page 511.
