Charles McMurray Co. 2021 Catalog

499 / 1590

1-21/32" min.
3" max.
(7 positions)
2-11/32" min.
3-11/16" max.
(7 positions)
KV8150 Series
Keyboard Slide BLACK Finish
3/4 Extension, Variable-Height
75 lb. Rating
• Mounting brackets adjust to 7 different heights and can
be reversed for inboard/outboard mounting
• Track member quickly disconnects using positive lever
release, easing installation
• Hold-in feature prevents keyboard tray bounce back
• Hold-out feature allows slide to be held in place when
drawer is open
• Ball-bearing action
Height: Overall drop height is adjustable from
2-11/32" to 3-11/16" in 7/32" increments
Clearance: 1-5/8" per side outboard
5/8" per side inboard
Polybagged 1 pair per bag with screws. 10 pair per box. Price
is per pair.
Item No. Length List Pair
List Pair
10
12" $63.54 $53.32
14" $65.92 $55.32
16" $67.88 $56.96
18" $69.58 $58.40
20" $71.10 $59.68
1/8" Rec.
2-11/32" min.
3-11/16" max.
(7 positions)
• Mounting brackets adjust to 7 different heights and can be
reversed for inboard/outboard mounting
• Anti-rebound stay-close design holds pencil drawer in
closed position yet allows for easy opening
• Track member quickly disconnects using positive lever
releases
• Ball-bearing action
Height: Overall drop height is adjustable from
2-11/32" to 3-11/16" in 7/32" increments
Clearance: 1-5/8" per side outboard position
17/32" per side inboard position
Polybagged 1 pair per bag with screws. 10 pair per box. Price
is per pair.
Item No. Length List Pair
List Pair
10
18" $72.68 $61.00
20" $74.30 $62.36
22" $76.18 $63.92
KV8250 Series
Pencil Drawer Slide
3/4 Extension, Variable-Height
75 lb. Rating
(shown in Anochrome)
Screws
#8 x 5/8", panhead phillips. Sold per hundred (c).
Item No. Description List c
List c
120
Coarse Thread $5.82 $4.44
Screws
#8 x 5/8", panhead phillips. Sold per hundred (c).
Item No. Description List c
List c
120
Coarse Thread $5.82 $4.44
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 2021 1946 499 Prices subject to change without notice.
