Features-
• Exceeds BHMA & KCMA performance requirements
• Four-way drawer adjusting; elongated and countersunk
mounting holes at front and rear provide four-way
drawer adjustment
• Ribbed slide profile and countersunk holes provide increased
rigidity and accommodate screw head protrusion
• Double-captive right-hand member eliminates side-play and
compensates for cabinet-to-drawer tolerance
• Positive stop in closed position prevents drawer damages,
detent holds drawer closed
• Double stop in extended position locks drawer open
• Lift-off disconnect drawer from cabinet
• Mounts with #6 flathead wood screws or Euro screws
• Bottom mount drawer member secures from side or bottom
• Self-lubricating 3-point injection-molded Acetel Copolymer
rollers are smooth, quiet, durable and maintenance free
• Hardened steel stud allows roller to self adjust
Height: 1-1/2" - 37 mm (with flange).
Clearance: 1/2" + 1/32" minus 0" each side.
Material: Heavy-duty 1.2 mm stamped-steel members.
Bulk pack 100 pair per box. Sold in full boxes only. Cabi-
net members and drawer members will be packed in 4 separate
boxes. Price is per pair. Order screws separately.
No. Size
List Pr.
100
List Pr.
500
450 mm (17-3/4") $9.44 $8.00
500 mm (19-11/16") $10.08 $8.48
550 mm (21-5/8") $11.44 $9.68
Bulk pack 100 members per box. Sold in full boxes only.
Cabinet and drawer members are packed separately. Order
screws separately.
No. Size
List Pr.
100
List Pr.
500
Cabinet Members, 1 LH & 1 RH
450 mm (17-3/4") $4.72 $4.00
500 mm (19-11/16") $5.04 $4.24
550 mm (21-5/8") $5.72 $4.84
Drawer Members, 1 LH & 1 RH
450 mm (17-3/4") $4.72 $4.00
500 mm (19-11/16") $5.04 $4.24
550 mm (21-5/8") $5.72 $4.84
LH=left hand, RH=right hand
MCES Standard Euro Slides
Bottom Mount, 3/4-Extension, Self-Closing
75 lb. Capacity, White Finish
24"
22"
20"
18"
16"
14"
12"
35 67 163 227 259 323 355 387
451 515
12.5
22.2
3.85"
2"
1.25"
Rear Mounting Sockets
No. Description Box List Ea.
Left Hand 500ea $0.90
Right Hand 500ea $0.90
Screws #6 x 1/2"
No. Box List Box
100 $5.04
1000 $30.36
5000 $133.64
