System 101 Front-Mounted Gang Lock System
Installation Details
Lock bar must
be restrained
from dropping
when in open
position.
Lock bar located
near front of case.
Item No. Description List Ea.
3/8" Adjustable Pin $1.70
Lock Body f/ 3/4" Material $8.38
Drawer Locking Clip $0.48
24" Lockbar $4.40
Lockbar Clip - non-handed $3.86
LP100* Lock Core - Nickel $10.40
LP300* Lock Core - Black $10.40
Lockbar Retainer $0.98
*Specify key #: LP100 - 100, 101, 102, 103, KD
LP300 - 100, 101
• Lock mounted in drawer front minimizing interference with hanging files
• Full 1/2" lockbar throw
• Fits within 1/2" drawer slide clearance
• Minimal machining required: Hole for lock & groove for lockbar
DC-500 Drawer Locking Clips
provide the preferred method of
locking drawers with 1/2" drawer
side clearance.
When used with the
AP-037 3/8" Adjustable
Pin, a strong, rigid lock
is provided.
More Drawer Clips and
Adjustable Pin sizes are
availableby special order.
Drawer Locking
3/8"
adjustable pin
(order 1 per
drawer)
drawer locking clip
(order 1 per drawer)
lock body
for 3/4" material 24" lockbar lockbar clip lockbar retainer Lock core includes 2 brass keys
LP100
Nickel
LP300
Black
