Item No. Installation
Bolt
Type
Cylinder
Length
Bolt
Travel List Ea. Stock Key #s
Door Dead 7/8" 3/4" $60.30 101, 107, 915
Drawer Dead 7/8" 3/4" $62.40 915
Drawer Dead 1-3/8" 3/4" $60.30 101, 107
Masterkeyed
Door Dead 7/8" 3/4" $52.68 01, 02, 03, KD
Drawer Dead 7/8" 3/4" $52.68 01, 02, 03
Drawer Dead 1-3/8" 3/4" $52.68 01, 02, 03
Item No. Description Bag List Ea.
Strike - Chamfered Inside 25 $3.58
Master Key (D4299) 1 $9.52
APPLICATIONS - For drawers, LH or RH doors. Surface mounted. Requires 57/64" diameter hole for cylinder.
OPERATION - Key removable in both locked and unlocked positions.
KEYING - Will key together with all other pin tumbler locks using D4291 key blank.
PACKAGING - Supplied with two keys, strike and mounting screws.
10 locks per box.
Pin Tumbler Door & Drawer Locks
"The Advantage Plus". Re-keying feature
allows you to remove the cylinder with
the lock still in place. Using a 5/64" allen
wrench from the back you can remove the
cylinder and plug.
Mounting Hole
C8173 C8178, C8179
57/64" dia.
All locks above are ANSI/BHMA certified Grade 2 A156.11.
Grade 1 locks are available as special order.
All locks are available for MRI applications.
Available:
Keyed alike
Masterkeyed keyed alike
Masterkeyed keyed different
Finishes
26D Satin Chrome
