Cams For DCN Locks
Item No. Description List Ea. List Ea. 10
Long Straight $4.42 $3.62
Z
X
Y
1-1/4"
1"
A
Typical Applications
DCN Pin Tumbler Cam Locks
Flush Overlay Lipped/Overlay
Mounting Cutout
Cam Lock Dimensions
For Mat.
Thickness
Straight
Cam (X)
Inbent
Cam (Y)
Outbent
Cam (Z)
Cylinder
Length (A)
DCN1 3/4" 1-1/16" 3/4" 1-3/8" 1"
DCN2 7/8" 1-3/16" 7/8" 1-1/2" 1-1/8"
DCN4 1-1/2" 1-13/16" 1-1/2" 2-1/8" 1-3/4"
Item No.
Material
Thickness
Cylinder
Length List Ea.
Stock
Key #s
Flat Black
3/4" 1" $64.04 01, KD
7/8" 1-1/8" $64.04 01
1-1/2" 1-3/4" $64.04 01
Oil-Rubbed Bronze
3/4" 1" $70.84 01
7/8" 1-1/8" $64.04 01
1-1/2" 1-3/4" $70.84 01
Satin Chrome
3/4" 1" $45.80 01
7/8" 1-1/8" $45.80 01, 02
1-1/2" 1-3/4" $45.80 01, 02
Item No. Description Box List Ea.
Masterkey 1 $8.16
• 5-pin National D4292 keyway
• Reversible cam, easy to install, higher security
• Includes straight cam, offset cam and 2 keys
• Masterkeys need to be ordered separately
• 10 locks per box
3"
3-1/2"
5/8" 3/32"
NOTE: Additional offset & straight cams available by special order.
Available:
Keyed alike
Keyed different
Masterkeyed
3/4" 5/8"
3/4"
Flat Black
Oil-Rubbed
Bronze
Satin Chrome
Includes straight and
offset cams
