324 / 1590
CSD-10-TV Series
Compact Soft-Down Lid Stays
For
Downward-Opening
Lids
• Soft-down stay for downward-opening flap door with
piano, butt,
or
drop hinge• Easy to install by aligning the body to the edge of a cabinet
• Designed for smaller cabinet doors in media centers or TV consoles
• Opening speed adjustable; the adjustment screw is located on back
for clean appearance
• Holds lid in closed position
• Non-handed
• Torque Calculation: Torque = Door height × 1/2 × Door Weight
L-Type (Light-Duty): 8.8-17.7 lbs./inch per each
Installation of Mounting Plate
Item No.
Type
Torque
Box List Ea.
List Ea.
10
Black Finish
CSD-10-TV-L-BLKLight
8.8-17.7 lbs./in. 10 $41.52 $35.18
White Finish
CSD-10-TV-H-WHTHeavy 26.6-35.4 lbs./in. 10 $41.52 $35.18
