Charles McMurray Co. 2021 Catalog

290a / 1590

• Lateral opening mechanism allows doors to swing out laterally in a
small radius, ideal for tight front space application
• 4-Way Adjustable: Vertical, horizontal, depth and parallel adjustment
• Built-in dampers provide smooth soft-closing movement
• Ideal for closet entryways, large pantry doors, storage, hidden rooms.
Can also be used on L-shaped corner spaces
• Non-handed, black or white finish
• Designed for overlay installation, can be installed flush with surrounding
cabinet or wall
Monoflat LIN-X800/800H Hinge Set
Lateral Opening Door System - Soft-Close
LIN-X800 LIN-X800H
Door Width 29-1/2" to 33-7/16" (750-850 mm)
Max. Door Height 94-1/2" (2400 mm) 117-5/16" (2980 mm)
Door Thickness 15/16" to 1-9/16" (24-40 mm)
Max. Door Weight 88.2 lbs. (40 kg/door)
Usage 1 set per door
08/22
Item No. Description List Set
Black $1,456.72
Black, Tall Door $1,522.92
White $1,456.72
White, Tall Door $1,522.92
8
Bracket covers
(4 hanging side/
4 leading edge)
2
Bar end covers
1
Connecting bar
2
Soft-close
hinge arms
Included in Set:
X800*
*Connecting bar to be cut by customer.
X800H
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 290a Prices subject to change without notice.
