Charles McMurray Co. 2021 Catalog

287 / 1590

GHC-34-8 Series Glass Door Hinges
• Half-overlay hinge with catch, for glass/acrylic doors
• Hinge will hold door in closed position without secondary support
• For door thickness: 4-6 mm
• Free-swinging
• Screws not included (recommended 2.7 x 16/S)
• Sold per each
• Max. Door Weight 8.8 lbs./pr.
• Max. Door Size:
Height 27-9/16"
Width 17-3/4"
Glass
Thickness
A
(mm)
Overlay
(mm)
4 (5/32") 19 7
5 (3/16") 18 6
6 (15/64") 17 5
Item No. Finish D1 D2 d T Box List Ea.
List Ea.
Full Box
Black 21 8 10 3 40 $21.74 $18.12
No. Part
Name Material Finish
1 Body 304 Stainless Steel Black
2 Plate Aluminum Black
3 Washer PVC Clear
4 Screw Steel Nickel
5 Catch Polyacetal Black
