Charles McMurray Co. 2021 Catalog

289 / 1590

H Overlay P S
0 15.5 16 16.5 17 6 19
3 12.5 13 13.5 14 9 22
6 9.5 10 10.5 11 12 25
9 6.5 7 7.5 8 15 28
5.5 6 6.5 7 fixed
distance
= 10 B = boring distance
NOTE: 4.5 plate is only for use in frame
cabinets, 9 plate is only for frameless cabinets
95° Glass Door Hinge - Glass Thickness 4.5 to 7 mm
66
H W
37
T
B
overlay
3
H
32 W
38.5 + T
T
67.5
Set
mounting
plate back
by glass
thickness
and height
of cover cap
B
reveal
No. Finish Box List Ea.
Chrome 50 $4.42
Black 50 $2.46
Boring Pattern Overlay Door
Cover Caps for Door Front (required)
Inset Door
Order hinge & covercap separately.
Overlay Hinge
Item No. List Ea. List Ea. 50
Self-Close
$9.42 $7.98
Order hinge & covercap separately.
Inset Hinge
Item No. List Ea. List Ea. 50
Self-Close
$10.02 $8.50
H Reveal P S
0 2.5 2 1.5 1 23.5 32
5.5 6 6.5 7 fixed
distance
= -8 B = boring distance
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
T = Door thickness
W = Side panel width
41 31
31
31 8.2 2.5
4.5 to 7
4.5 to 7
5.5 to 7
Ø26
Frameless Frameless
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Item No. List Ea.
$102.96
26 mm Drill Bit
Minimum Reveal Table
5.5 0 0 0 0
6 0 0 0 0
6.5 0 0 0 0
7 0 0 0 0
B =
boring
distance
4.5 5 6 7
T = door thickness
For thickness greater than 7 mm a
trial is recommended. Cross-refer-
ence the door thickness and bore
distance to assure that doors won't
bind when opened.
Features
• Available in Self-Close
• Three-dimensional adjustment
• Side adjustment of +.5 to -3.5 mm
• Fixing screws included (605.1100)
• Must use 26 mm drill bit (1" cannot be used
(Order
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 289 Prices subject to change without notice.
