Charles McMurray Co. 2021 Catalog

1394 / 1590

JH1700 Folding Door Hardware
For 2 or 4 Doors, 3/4" to 1-3/4" Thick, Up To 40 lbs. Each
• Brown steel track blends with all stained or natural finish doors
• Track may be cut-down to accommodate narrower panel/
openings
• Surface-mounted pivots and guides (no hole drilling)
• Four-way adjustable bottom pivot brackets and shock-
absorbing hinges self-locate and automatically align doors
• Residential grade
Top Pivot
Bottom Pivot
Snubber (track stop)
Jamb Bracket
Brown
Knob
w/screw
Hinge
Aligner
Item No. Description Box List
Bi-Fold Hinge, Zinc 12 ea $4.80 ea
Channel Guide 100 ea $3.00 ea
Adjustment Wrench 100 ea $1.58 ea
Aligner f/4 door application 10 pr $2.22 pr
Packaged Sets - Includes track & hardware
Item No. Size
No. of
Doors Box List Set
36" 2 5 $38.78
48" 4 5 $66.30
60" 4 5 $69.60
72" 4 5 $73.84
Components
NOTES:
For folding door accessories see pages 1395-1399.
Installation instructions and videos are available at
under the Resources tab.
Packaged Sets Include
2-Door
Set
4-Door
Sets
1 ea 1 ea JH1700 Series track length
1 ea 2 ea JH1701 top pivot
3 ea 6 ea JH1703 panel hinges
1 ea 2 ea JH1705 panel guide
1 ea 2 ea JH1707 bottom pivot
1 ea 2 ea JH1710 top pivot lock
1 ea 2 ea JH1711 bottom pivot bracket
1 ea 1 ea JH1712 adjustment wrench
1 ea 2 ea JH1713 track stop
--- 1 pr JH1808 converging panel aligner
1 ea 2 ea JH33 knob
mounting screws
Channel Guide
0
Pivot Lock
3/4x2-1/4" plate
Wrench
Maximum panel weight: 40 lbs. per panel
Maximum panel width: 24" per panel
Maximum panel height: 96"
door height +2"
7/8"
25/32"
Box Track Profile
