Charles McMurray Co. 2021 Catalog

1391 / 1590

Folding Door Hardware
For Two or Four Doors,
3/4" to 1-3/4" Thick, Up To 50 lbs. Each
*LTL ONLY
item on
this page
Bulk Pack
Track, Hardware Set & Hinges sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
JH111-60 60" 25 $23.92 $19.78
JH111-72 72" 25 $28.38 $23.46
JH111-96 96" 25 $36.76 $30.64
JH111-120 120" 10 $61.70 $54.14
JH111-144 144" 10 $75.34 $66.12
JH111-192* 192" 10 $95.72 $84.46
* Must ship LTL
2-Door Hardware Set Includes
1 ea JH1020 hanger 1 ea JH1155 track stop
1 ea JH1711 bottompivot bracket 1 ea JH1707 bottom pivot
1 ea JH33 knob 1/2 pr JH1808 aligner
1 ea JH118 top pivot set 1 ea JH1712 adj wrench
Item No. Description Box List
JH1020BULK Hanger (bulk-full box) 50 ea $7.62 ea
JH1020PLB2 Hanger 50 pr $15.94 pr
JH1155 Track Stop 100 ea $3.14 ea
JH1703 Hinge 12 ea $4.80 ea
Adjustment Wrench 100 ea $1.58 ea
JH1808 Aligner f/4 doors 10 pr $2.22 pr
JH33 Brown Knob
w/Screw
JH1020 Hanger
JH118 Top Pivot
JH1707
Bottom Pivot
JH1808
4 Door Aligner
w/screws
1x3" plate
JH1155 Track Stop
Components
Nylon Wheels: 3/4" dia.
Plate: 3/4" x 2-1/4" JH1703 Shock-
Absorbing Hinge
JH1711AdjustableBottom
Pivot Bracket - Mounts on
jamb - not floor.
Box Track Profile
1.21" (30.7mm)
1.037" (26.3mm)
• Top-hung system for heavier doors
• Four-way adjustable bottom pivot brackets and shock-absorbing
hinges self-locate and automatically align doors
• Compact aluminum convex rail box track design
• Track can be cut-down to accommodate narrower panel/openings
• 3-wheel hangers are permanently lubricated and adjustable
• Self-locating "breathing" hinges
• Commercial grade; also suitable for residential applications
• Track, hinges and hardware set are sold separately
ROOM SIDE
Finished Opening HeightDoor Height + 2-3/4"
One hardware set will pivot two doors from a jamb.
2-Door Hardware Set (order hinges separately)
Item No. Description Box List Set
List Set
Full Box
JH11311107 For 50 lb. doors 25 $30.10 $25.08
NOTES:
For 4 doors, 2 from each side, order 2 hardware sets. Not recommended
for 4 doors from one side.
For folding door accessories/components see pages 1395-1399.
Installation instructions are available at
under the Resources tab.
This track can also be used for:
Bypass Doors..... page 1361
Pocket Doors..... page 1377
Wrench
Maximum panel weight: 50 lbs. per panel
Maximum panel width: 24" per panel
Maximum panel height: 108"
