Charles McMurray Co. 2021 Catalog

1390 / 1590

Folding Door Hardware
For Two or Four Doors, 1" to 1-3/4" Thick
One hardware set will pivot two doors from a jamb.
Order an additional hanger for each additional pair of doors.
Finished Opening Height = Door Height + 2-7/8"
Components
*LTL ONLY
item on
this page
2-Door Hardware Set Includes
1 ea pivot set w/screws 1 ea stop
1 ea hanger w/screws 1 ea floor bracket
1/2 pr aligner w/screws 1 ea knob w/screws
1 ea long bottom pivot 1 ea wrench
Non-Mortise Lift-Off
Hinges w/screws
Long Bottom
(2-1/4x1") Pivot
w/screws
Ball-Bearing Hanger
w/plate (1x3") & screws
Pivot Set
w/screws
Track Stop
4 Door Aligner
w/screws
Brown
Knob w/Screw Floor Bracket
Maximum panel weight:
Two Doors on one side - Up To 75 lbs. per panel
Two Doors on each side - Up To 75 lbs. per panel
Four Doors on one side - Up to 50 lbs. panel
Maximum panel width: 24" per panel
Maximum panel height: 108"
1" dia. wheels
JH1606
brass
JH1603
zinc
Bulk Pack
Track, Hardware Set & Hinges sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
JH100-48 48" 25 $26.08 $21.66
JH100-60 60" 25 $32.04 $26.60
JH100-72 72" 25 $37.32 $31.10
JH100-96 96" 10 $52.46 $43.72
JH100-120 120 10 $77.14 $67.70
JH100-144 144" 10 $92.28 $81.20
JH100-192* 192" 10 $129.40 $113.56
* Must ship LTL
• Aluminum convex rail box track design
• Patented tricycle hangers with large ball-bearing wheels
glide smoothly and quietly
• Hangers feature quick disconnect clip system for easy
mounting or dismounting of door panels
• Commercial grade; also suitable for residential applications
NOTES:
For 4 doors, 2 from each side, order 2 hardware sets.
For 4 doors from one side order 1 hardware set and 1 hanger.
For folding door accessories/components see pages 1395-1399.
Installation instructions are available at
under the Resources tab.
This track can also be used for:
Bypass Doors...........page 1360
Pocket Doors...........page 1376
Wrench
2-Door Hardware Set (order hinges separately)
Item No. Description Box List Set
List Set
Full Box
JH1031FD06 For 75 lb. doors 25 $38.50 $32.72
Item No. Description Box List
JH1125BULK Hanger (bulk each-full box) 50 ea $16.22 ea
JH1125PLB2 Hanger (pair) 50 pr $31.98 pr
JH1155 Track Stop 100 ea $3.14 ea
JH1603ZC Lift-Off Hinge-Zinc 50 ea $4.48 ea
JH1606BB Lift-Off Hinge-Brass 50 ea $5.54 ea
Adjustment Wrench 100 ea $1.58 ea
JH1808 Aligner f/4 doors 10 pr $2.22 pr
Box Track Profile
1.787" (45mm)
1.242" (32mm)
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1390 Prices subject to change without notice.
