Charles McMurray Co. 2021 Catalog

1393 / 1590

JH1601 Folding Door Hardware
100% Accessible
For Two 1-1/8" to 1-3/4" Doors, Up To 30 lbs. Each
Item No. Description Box List Ea.
Door Bumper 100 $0.90 ea
Shock-Absorbing Hinge 12 $4.80 ea
Aligner 10pr $2.22 pr
JH1601 control arm
2-Door Set Includes
1 ea JH1601 control arm 1 ea door bumper
3 ea lift-off hinge 1/2 pr converging panel aligner
3 ea panel hinge 1 ea JH33 knob
Hardware mounting screws
• 100% full-access jamb-to-jamb, with doors folding 180° and lying flat against the wall
• Patented non-mortise lift-off jamb hinges (can also be used with standard mortise butt hinges to match other interior doors)
• Shock-absorbing panel hinge, self-locating with its door spacing fingers
• Wood-tone aluminum control arm; no top track needed
- Shock-absorbing hinge, self-locating with its door spac-
ing fingers, that "breathes" if any hinge binding or shock of door
opening is encountered.
Aligner
(includes 1/2 pair) Door Bumper
Item No.
Panel
Width
Nominal Door
Opening Widths
List Set 2 Doors 4 Doors
12" to 18" 24" to 36" 48" to 72" $76.28
FULL
ACCESS
Components & Accessories
Maximum panel weight w/non-mortise hinge: 30 lbs. per panel
Maximum panel width: 18" per panel
Maximum panel height: 96"
Packaged set is for two 12" to 18" doors - use two sets for four
doors. Hardware mounting screws are included.
NOTES:
For folding door accessories/components see pages 1395-1399.
Installation instructions and videos are available at
under the Resources tab.
Brown Knob
w/screw
Four doors shown Four doors shown
